Wifi not coming up after suspend

qubbeeeslayer · January 25, 2026, 4:58am

cat /rw/config/suspend-module-blacklist
# You can list modules here that you want to be unloaded before going to sleep. This
# file is used only if the VM has any PCI device assigned. Modules will be
# automatically re-loaded after resume.
iwlmld
iwlwifi
mac80211
cfg80211

as you can see all the possible modules are listed in there, though when coming up from a laptop suspend it won’t know about wifi. i have to restart sys-net every time i pick up the laptop.
in general this isnt a porblem on other distributions such as ubuntu/fedora so i dont think its the hardware. i have a t14g5 intel

what should i do? would a dmesg be useful? the last boot dmesg won’t be available since sys-net is disposable

im running latest qubes os 4.3

these are the drivers in use:

[user@sys-net ~]$ lsmod | grep iwl
iwlmld                446464  0
mac80211             1925120  1 iwlmld
iwlwifi               585728  1 iwlmld
cfg80211             1523712  3 iwlmld,iwlwifi,mac80211

qubbeeeslayer · January 25, 2026, 5:04am

here is a dmesg of what’s happening after suspend/resume:

[  902.834960] e1000e 0000:00:07.0 ens7: NIC Link is Down
[  903.214088] wls6: deauthenticating from ff:ff:ff:ff:ff by local choice (Reason: 3=DEAUTH_LEAVING)
[  903.820031] e1000e 0000:00:07.0 ens7: removed PHC
[  903.865497] ehci-pci 0000:00:05.0: remove, state 4
[  903.865527] usb usb1: USB disconnect, device number 1
[  903.865535] usb 1-1: USB disconnect, device number 2
[  903.876690] ehci-pci 0000:00:05.0: USB bus 1 deregistered
[  904.083562] Freezing user space processes
[  904.086313] Freezing user space processes completed (elapsed 0.002 seconds)
[  904.086339] OOM killer disabled.
[  904.086350] Freezing remaining freezable tasks
[  904.087318] Freezing remaining freezable tasks completed (elapsed 0.000 seconds)
[  904.087342] xen:manage: Using freeze/restore/thaw for sleep/wakeup
[  904.089236] suspending xenstore...
[  904.102884] xen:grant_table: Grant tables using version 1 layout
[  904.181174] OOM killer enabled.
[  904.181188] Restarting tasks: Starting
[  904.183506] Restarting tasks: Done
[  905.529655] prepare-suspend (1356): drop_caches: 3
[  905.568253] ehci-pci 0000:00:05.0: EHCI Host Controller
[  905.568534] ehci-pci 0000:00:05.0: new USB bus registered, assigned bus number 1
[  905.569508] ehci-pci 0000:00:05.0: irq 39, io mem 0xf2037000
[  905.575491] ehci-pci 0000:00:05.0: USB 2.0 started, EHCI 1.00
[  905.575707] usb usb1: New USB device found, idVendor=1d6b, idProduct=0002, bcdDevice= 6.17
[  905.575731] usb usb1: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[  905.575754] usb usb1: Product: EHCI Host Controller
[  905.575782] usb usb1: Manufacturer: Linux 6.17.9-1.qubes.fc41.x86_64 ehci_hcd
[  905.575808] usb usb1: SerialNumber: 0000:00:05.0
[  905.576003] hub 1-0:1.0: USB hub found
[  905.576024] hub 1-0:1.0: 6 ports detected
[  905.624277] cfg80211: Loading compiled-in X.509 certificates for regulatory database
[  905.624688] Loaded X.509 cert 'sforshee: 00b28ddf47aef9cea7'
[  905.624775] Loaded X.509 cert 'wens: 61c038651aabdcf94bd0ac7ff06c7248db18c600'
[  905.656203] iwlwifi 0000:00:06.0: Detected crf-id 0x2001910, cnv-id 0x2001910 wfpm id 0x80000000
[  905.656689] iwlwifi 0000:00:06.0: PCI dev 272b/00f0, rev=0x472, rfid=0x112200
[  905.656725] iwlwifi 0000:00:06.0: Detected Intel(R) Wi-Fi 7 BE200 320MHz
[  905.659372] iwlwifi 0000:00:06.0: Direct firmware load for iwlwifi-gl-c0-fm-c0-102.ucode failed with error -2
[  905.734080] e1000e 0000:00:07.0: Interrupt Throttling Rate (ints/sec) set to dynamic conservative mode
[  905.736962] iwlwifi 0000:00:06.0: loaded firmware version 101.6ef20b19.0 gl-c0-fm-c0-101.ucode op_mode iwlmld
[  905.768170] kworker/0:2: page allocation failure: order:7, mode:0x40dc0(GFP_KERNEL|__GFP_ZERO|__GFP_COMP), nodemask=(null),cpuset=/,mems_allowed=0
[  905.768222] CPU: 0 UID: 0 PID: 68 Comm: kworker/0:2 Not tainted 6.17.9-1.qubes.fc41.x86_64 #1 PREEMPT(full)
[  905.768225] Hardware name: Xen HVM domU, BIOS 4.19.4 01/05/2026
[  905.768227] Workqueue: events request_firmware_work_func
[  905.768232] Call Trace:
[  905.768234]  <TASK>
[  905.768237]  dump_stack_lvl+0x5d/0x80
[  905.768241]  warn_alloc+0x162/0x190
[  905.768245]  ? __alloc_pages_direct_compact+0x1bc/0x220
[  905.768247]  __alloc_pages_slowpath.constprop.0+0x566/0xaf0
[  905.768250]  __alloc_frozen_pages_noprof+0x2ee/0x340
[  905.768256]  ? iwl_pcie_rx_alloc+0x72/0x320 [iwlwifi]
[  905.768275]  alloc_pages_mpol+0x7d/0x180
[  905.768278]  ___kmalloc_large_node+0xa6/0xe0
[  905.768285]  __kmalloc_large_node_noprof+0x21/0xb0
[  905.768287]  __kmalloc_noprof+0x3e2/0x560
[  905.768290]  ? iwl_pcie_rx_alloc+0x72/0x320 [iwlwifi]
[  905.768304]  iwl_pcie_rx_alloc+0x72/0x320 [iwlwifi]
[  905.768318]  _iwl_pcie_rx_init+0x3b0/0x3e0 [iwlwifi]
[  905.768332]  ? _raw_spin_unlock_bh+0xe/0x20
[  905.768335]  ? iwl_finish_nic_init+0x73/0x2a0 [iwlwifi]
[  905.768347]  iwl_trans_pcie_gen2_start_fw+0x1c7/0x850 [iwlwifi]
[  905.768366]  ? iwl_dbg_tlv_init_cfg+0x363/0x3b0 [iwlwifi]
[  905.768385]  iwl_trans_start_fw+0x7b/0xa0 [iwlwifi]
[  905.768404]  iwl_mld_load_fw_wait_alive+0x9e/0x140 [iwlmld]
[  905.768418]  ? __pfx_iwl_alive_fn+0x10/0x10 [iwlmld]
[  905.768426]  iwl_mld_run_fw_init_sequence+0x66/0x1b0 [iwlmld]
[  905.768435]  ? _iwl_trans_pcie_start_hw+0x22b/0x2b0 [iwlwifi]
[  905.768452]  iwl_mld_load_fw+0x33/0x90 [iwlmld]
[  905.768460]  iwl_op_mode_mld_start+0x1dd/0x360 [iwlmld]
[  905.768471]  _iwl_op_mode_start+0x5a/0xe0 [iwlwifi]
[  905.768484]  ? iwl_dbg_tlv_load_bin+0x13d/0x150 [iwlwifi]
[  905.768501]  iwl_req_fw_callback+0x88b/0xb80 [iwlwifi]
[  905.768514]  request_firmware_work_func+0x51/0xa0
[  905.768517]  process_one_work+0x18a/0x340
[  905.768520]  worker_thread+0x256/0x3a0
[  905.768523]  ? __pfx_worker_thread+0x10/0x10
[  905.768525]  kthread+0xf9/0x240
[  905.768527]  ? __pfx_kthread+0x10/0x10
[  905.768528]  ? __pfx_kthread+0x10/0x10
[  905.768529]  ret_from_fork+0xf2/0x110
[  905.768532]  ? __pfx_kthread+0x10/0x10
[  905.768534]  ret_from_fork_asm+0x1a/0x30
[  905.768537]  </TASK>
[  905.770066] Mem-Info:
[  905.770081] active_anon:1045 inactive_anon:2007 isolated_anon:0
                active_file:1960 inactive_file:4615 isolated_file:0
                unevictable:0 dirty:102 writeback:18
                slab_reclaimable:2141 slab_unreclaimable:11209
                mapped:6589 shmem:11 pagetables:1582
                sec_pagetables:0 bounce:0
                kernel_misc_reclaimable:0
                free:12230 free_pcp:20 free_cma:0
[  905.770207] Node 0 active_anon:4180kB inactive_anon:8028kB active_file:7840kB inactive_file:18460kB unevictable:0kB isolated(anon):0kB isolated(file):0kB mapped:26356kB dirty:408kB writeback:36kB shmem:44kB shmem_thp:0kB shmem_pmdmapped:0kB anon_thp:0kB kernel_stack:3600kB pagetables:6328kB sec_pagetables:0kB all_unreclaimable? no Balloon:16384kB
[  905.772307] Node 0 DMA free:7036kB boost:0kB min:1448kB low:1808kB high:2168kB reserved_highatomic:0KB free_highatomic:0KB active_anon:720kB inactive_anon:1192kB active_file:792kB inactive_file:572kB unevictable:0kB writepending:20kB present:15992kB managed:15360kB mlocked:0kB bounce:0kB free_pcp:12kB local_pcp:12kB free_cma:0kB
[  905.772388] lowmem_reserve[]: 0 197 197 197 197
[  905.772410] Node 0 DMA32 free:43288kB boost:0kB min:19028kB low:23784kB high:28540kB reserved_highatomic:0KB free_highatomic:0KB active_anon:2728kB inactive_anon:7368kB active_file:8072kB inactive_file:15536kB unevictable:0kB writepending:1008kB present:274428kB managed:201880kB mlocked:0kB bounce:0kB free_pcp:192kB local_pcp:76kB free_cma:0kB
[  905.772489] lowmem_reserve[]: 0 0 0 0 0
[  905.772506] Node 0 DMA: 386*4kB (UME) 176*8kB (UME) 94*16kB (UME) 47*32kB (UME) 11*64kB (UME) 3*128kB (UM) 0*256kB 0*512kB 0*1024kB 0*2048kB 0*4096kB = 7048kB
[  905.772568] Node 0 DMA32: 955*4kB (UME) 1036*8kB (UME) 746*16kB (UME) 294*32kB (UME) 94*64kB (UME) 26*128kB (UME) 2*256kB (UM) 0*512kB 0*1024kB 0*2048kB 0*4096kB = 43308kB
[  905.772621] Node 0 hugepages_total=0 hugepages_free=0 hugepages_surp=0 hugepages_size=1048576kB
[  905.772649] Node 0 hugepages_total=0 hugepages_free=0 hugepages_surp=0 hugepages_size=2048kB
[  905.772673] 7716 total pagecache pages
[  905.772684] 1486 pages in swap cache
[  905.772694] Free swap  = 914300kB
[  905.772715] Total swap = 1048572kB
[  905.772726] 72605 pages RAM
[  905.772743] 0 pages HighMem/MovableOnly
[  905.772754] 18295 pages reserved
[  905.772765] 0 pages cma reserved
[  905.772775] 0 pages hwpoisoned
[  905.772807] iwlwifi 0000:00:06.0: Unable to init nic
[  905.813323] usb 1-1: new high-speed USB device number 2 using ehci-pci
[  905.814439] e1000e 0000:00:07.0 0000:00:07.0 (uninitialized): registered PHC clock
[  905.867897] iwlwifi 0000:00:06.0: Unable to init nic
[  905.957566] iwlwifi 0000:00:06.0: Unable to init nic

any ideas?

qubbeeeslayer · January 26, 2026, 9:56pm

after a discussion on 4chan i was led to the following github issue:

github.com/QubesOS/qubes-issues

Intel BE200 Wifi Adapter not available after resuming from suspend state

opened 08:26PM - 27 Mar 25 UTC

closed 01:42AM - 06 Apr 25 UTC

henrypotgieter

P: major hardware support diagnosed pr submitted C: networking C: power management r4.2-vm-bookworm-stable affects-4.2 r4.2-vm-trixie-stable r4.2-vm-fc40-stable r4.3-vm-bookworm-cur-test r4.3-vm-trixie-cur-test r4.3-vm-fc40-cur-test r4.3-vm-fc41-cur-test r4.2-vm-fc41-stable r4.2-stable r4.3-vm-fc42-cur-test certified hardware

### Brief summary I am having problems with a Novacustom V56 laptop when using… the Intel BE200 wifi 7 NIC. After suspending and then resuming the system the BE200 disappears from the available adapters in the sys-net vm. Today I installed the system using Qubes-R4.2.4-x86_64.iso using the kernel_latest option. I am using standard install options with my sys-net VM based off fedora-41-xfce. The system has been patched. Current kernel is 6.13.7-1.qubes.fc37.x86_64 (I see this matching in dom0 and sys-net) ### Steps to reproduce Resume system after suspending the system to memory via the UI or suspend by closing the lid. ### Expected behavior The wireless adapter will still be present in sys-net and will reconnect to the network. ### Actual behavior The adapter is not present. ### Additional information I captured data from both dom0 and sys-net from when things were working before suspend, and when they weren't after suspend: #### Before **sys-net# dmesg | grep wifi** <details> ``` > [ 3.134514] iwlwifi 0000:00:07.0: Detected crf-id 0x2001910, cnv-id 0x2001910 wfpm id 0x80000000 > [ 3.134631] iwlwifi 0000:00:07.0: PCI dev 272b/00f4, rev=0x472, rfid=0x112200 > [ 3.134655] iwlwifi 0000:00:07.0: Detected Intel(R) Wi-Fi 7 BE200 320MHz > [ 3.266294] iwlwifi 0000:00:07.0: TLV_FW_FSEQ_VERSION: FSEQ Version: 0.0.4.191 > [ 3.267297] iwlwifi 0000:00:07.0: loaded firmware version 94.62990553.0 gl-c0-fm-c0-94.ucode op_mode iwlmvm > [ 3.742162] iwlwifi 0000:00:07.0: loaded PNVM version 97f4ce1a > [ 3.762211] iwlwifi 0000:00:07.0: Detected RF FM, rfid=0x112200 > [ 3.854811] iwlwifi 0000:00:07.0: base HW address: 44:a3:bb:8d:9d:98 > [ 3.947696] iwlwifi 0000:00:07.0 wls7f0: renamed from wlan0 > [ 5.057881] iwlwifi 0000:00:07.0: Registered PHC clock: iwlwifi-PTP, with index: 1 ``` </details> **sys-net# lspci -vvv -s 00:07.0** <details> ``` > 00:07.0 Network controller: Intel Corporation Wi-Fi 7(802.11be) AX1775*/AX1790*/BE20*/BE401/BE1750* 2x2 (rev 1a) > Subsystem: Intel Corporation BE200 320MHz [Gale Peak] > Physical Slot: 7 > Control: I/O- Mem+ BusMaster+ SpecCycle- MemWINV- VGASnoop- ParErr- Stepping- SERR- FastB2B- DisINTx+ > Status: Cap+ 66MHz- UDF- FastB2B- ParErr- DEVSEL=fast >TAbort- <TAbort- <MAbort- >SERR- <PERR- INTx- > Latency: 0 > Interrupt: pin A routed to IRQ 44 > Region 0: Memory at f2030000 (64-bit, non-prefetchable) [size=16K] > Capabilities: [40] Power Management version 3 > Flags: PMEClk- DSI- D1- D2- AuxCurrent=0mA PME(D0-,D1-,D2-,D3hot-,D3cold-) > Status: D0 NoSoftRst+ PME-Enable- DSel=0 DScale=0 PME- > Capabilities: [50] MSI: Enable- Count=1/1 Maskable- 64bit+ > Address: 0000000000000000 Data: 0000 > Capabilities: [70] Express (v2) Endpoint, IntMsgNum 0 > DevCap: MaxPayload 128 bytes, PhantFunc 0, Latency L0s unlimited, L1 unlimited > ExtTag- AttnBtn- AttnInd- PwrInd- RBE+ FLReset- SlotPowerLimit 10W TEE-IO- > DevCtl: CorrErr- NonFatalErr- FatalErr- UnsupReq- > RlxdOrd+ ExtTag- PhantFunc- AuxPwr- NoSnoop+ > MaxPayload 128 bytes, MaxReadReq 512 bytes > DevSta: CorrErr- NonFatalErr- FatalErr- UnsupReq- AuxPwr+ TransPend- > LnkCap: Port #0, Speed 16GT/s, Width x1, ASPM L1, Exit Latency L1 <64us > ClockPM+ Surprise- LLActRep- BwNot- ASPMOptComp+ > LnkCtl: ASPM Disabled; RCB 64 bytes, LnkDisable- CommClk- > ExtSynch- ClockPM- AutWidDis- BWInt- AutBWInt- > LnkSta: Speed 16GT/s, Width x1 > TrErr- Train- SlotClk+ DLActive- BWMgmt- ABWMgmt- > DevCap2: Completion Timeout: Not Supported, TimeoutDis+ NROPrPrP- LTR+ > 10BitTagComp+ 10BitTagReq- OBFF Not Supported, ExtFmt- EETLPPrefix- > EmergencyPowerReduction Not Supported, EmergencyPowerReductionInit- > FRS- TPHComp- ExtTPHComp- > AtomicOpsCap: 32bit- 64bit- 128bitCAS- > DevCtl2: Completion Timeout: 50us to 50ms, TimeoutDis- > AtomicOpsCtl: ReqEn- > IDOReq- IDOCompl- LTR- EmergencyPowerReductionReq- > 10BitTagReq- OBFF Disabled, EETLPPrefixBlk- > LnkSta2: Current De-emphasis Level: -6dB, EqualizationComplete+ EqualizationPhase1+ > EqualizationPhase2+ EqualizationPhase3+ LinkEqualizationRequest- > Retimer- 2Retimers- CrosslinkRes: Upstream Port > Capabilities: [b0] MSI-X: Enable+ Count=32 Masked- > Vector table: BAR=0 offset=00002000 > PBA: BAR=0 offset=00003000 > Kernel driver in use: iwlwifi > Kernel modules: iwlwifi ``` </details> **dom0# lspci -vvv 0s 2f:00.0** <details> ``` > 2f:00.0 Network controller: Intel Corporation Device 272b (rev 1a) > Subsystem: Intel Corporation Device 00f4 > Control: I/O- Mem+ BusMaster+ SpecCycle- MemWINV- VGASnoop- ParErr- Stepping- SERR- FastB2B- DisINTx+ > Status: Cap+ 66MHz- UDF- FastB2B- ParErr- DEVSEL=fast >TAbort- <TAbort- <MAbort- >SERR- <PERR- INTx- > Latency: 0, Cache Line Size: 64 bytes > Interrupt: pin A routed to IRQ 19 > Region 0: Memory at b5500000 (64-bit, non-prefetchable) [size=16K] > Capabilities: [40] Power Management version 3 > Flags: PMEClk- DSI- D1- D2- AuxCurrent=375mA PME(D0+,D1-,D2-,D3hot+,D3cold+) > Status: D0 NoSoftRst+ PME-Enable- DSel=0 DScale=0 PME- > Capabilities: [50] MSI: Enable- Count=1/1 Maskable- 64bit+ > Address: 0000000000000000 Data: 0000 > Capabilities: [70] Express (v2) Endpoint, MSI 00 > DevCap: MaxPayload 128 bytes, PhantFunc 0, Latency L0s unlimited, L1 unlimited > ExtTag- AttnBtn- AttnInd- PwrInd- RBE+ FLReset+ SlotPowerLimit 10W > DevCtl: CorrErr+ NonFatalErr+ FatalErr+ UnsupReq+ > RlxdOrd+ ExtTag- PhantFunc- AuxPwr- NoSnoop+ FLReset- > MaxPayload 128 bytes, MaxReadReq 512 bytes > DevSta: CorrErr- NonFatalErr- FatalErr- UnsupReq- AuxPwr+ TransPend- > LnkCap: Port #0, Speed 16GT/s, Width x1, ASPM L1, Exit Latency L1 <64us > ClockPM+ Surprise- LLActRep- BwNot- ASPMOptComp+ > LnkCtl: ASPM L1 Enabled; RCB 64 bytes, Disabled- CommClk+ > ExtSynch- ClockPM+ AutWidDis- BWInt- AutBWInt- > LnkSta: Speed 16GT/s, Width x1 > TrErr- Train- SlotClk+ DLActive- BWMgmt- ABWMgmt- > DevCap2: Completion Timeout: Not Supported, TimeoutDis+ NROPrPrP- LTR+ > 10BitTagComp+ 10BitTagReq- OBFF Not Supported, ExtFmt- EETLPPrefix- > EmergencyPowerReduction Not Supported, EmergencyPowerReductionInit- > FRS- TPHComp- ExtTPHComp- > AtomicOpsCap: 32bit- 64bit- 128bitCAS- > DevCtl2: Completion Timeout: 50us to 50ms, TimeoutDis+ LTR+ 10BitTagReq- OBFF Disabled, > AtomicOpsCtl: ReqEn- > LnkCap2: Supported Link Speeds: 2.5-16GT/s, Crosslink- Retimer+ 2Retimers+ DRS- > LnkCtl2: Target Link Speed: 16GT/s, EnterCompliance- SpeedDis- > Transmit Margin: Normal Operating Range, EnterModifiedCompliance- ComplianceSOS- > Compliance Preset/De-emphasis: -6dB de-emphasis, 0dB preshoot > LnkSta2: Current De-emphasis Level: -6dB, EqualizationComplete+ EqualizationPhase1+ > EqualizationPhase2+ EqualizationPhase3+ LinkEqualizationRequest- > Retimer- 2Retimers- CrosslinkRes: Upstream Port > Capabilities: [b0] MSI-X: Enable+ Count=32 Masked- > Vector table: BAR=0 offset=00002000 > PBA: BAR=0 offset=00003000 > Capabilities: [100 v2] Advanced Error Reporting > UESta: DLP- SDES- TLP- FCP- CmpltTO- CmpltAbrt- UnxCmplt- RxOF- MalfTLP- ECRC- UnsupReq- ACSViol- > UEMsk: DLP- SDES- TLP- FCP- CmpltTO- CmpltAbrt- UnxCmplt- RxOF- MalfTLP- ECRC- UnsupReq- ACSViol- > UESvrt: DLP+ SDES+ TLP- FCP+ CmpltTO- CmpltAbrt- UnxCmplt- RxOF+ MalfTLP+ ECRC- UnsupReq- ACSViol- > CESta: RxErr- BadTLP- BadDLLP- Rollover- Timeout- AdvNonFatalErr- > CEMsk: RxErr- BadTLP- BadDLLP- Rollover- Timeout- AdvNonFatalErr+ > AERCap: First Error Pointer: 00, ECRCGenCap+ ECRCGenEn- ECRCChkCap+ ECRCChkEn- > MultHdrRecCap+ MultHdrRecEn- TLPPfxPres- HdrLogCap- > HeaderLog: 00000000 00000000 00000000 00000000 > Capabilities: [148 v1] Secondary PCI Express > LnkCtl3: LnkEquIntrruptEn- PerformEqu- > LaneErrStat: 0 > Capabilities: [158 v1] Physical Layer 16.0 GT/s <?> > Capabilities: [17c v1] Lane Margining at the Receiver <?> > Capabilities: [188 v1] Latency Tolerance Reporting > Max snoop latency: 15728640ns > Max no snoop latency: 15728640ns > Capabilities: [190 v1] L1 PM Substates > L1SubCap: PCI-PM_L1.2+ PCI-PM_L1.1+ ASPM_L1.2+ ASPM_L1.1+ L1_PM_Substates+ > PortCommonModeRestoreTime=10us PortTPowerOnTime=14us > L1SubCtl1: PCI-PM_L1.2+ PCI-PM_L1.1+ ASPM_L1.2+ ASPM_L1.1+ > T_CommonMode=0us LTR1.2_Threshold=116736ns > L1SubCtl2: T_PwrOn=50us > Capabilities: [1a0 v1] Vendor Specific Information: ID=0002 Rev=4 Len=100 <?> > Capabilities: [2a0 v1] Data Link Feature <?> > Capabilities: [2ac v1] Precision Time Measurement > PTMCap: Requester:+ Responder:- Root:- > PTMClockGranularity: Unimplemented > PTMControl: Enabled:+ RootSelected:- > PTMEffectiveGranularity: 4ns > Capabilities: [2b8 v1] Vendor Specific Information: ID=0003 Rev=1 Len=054 <?> > Capabilities: [500 v1] Vendor Specific Information: ID=0023 Rev=1 Len=010 <?> > Kernel driver in use: pciback > Kernel modules: iwlwifi ``` </details> #### After **sys-net# dmesg | grep wifi** <details> ``` > [ 3.134514] iwlwifi 0000:00:07.0: Detected crf-id 0x2001910, cnv-id 0x2001910 wfpm id 0x80000000 > [ 3.134631] iwlwifi 0000:00:07.0: PCI dev 272b/00f4, rev=0x472, rfid=0x112200 > [ 3.134655] iwlwifi 0000:00:07.0: Detected Intel(R) Wi-Fi 7 BE200 320MHz > [ 3.266294] iwlwifi 0000:00:07.0: TLV_FW_FSEQ_VERSION: FSEQ Version: 0.0.4.191 > [ 3.267297] iwlwifi 0000:00:07.0: loaded firmware version 94.62990553.0 gl-c0-fm-c0-94.ucode op_mode iwlmvm > [ 3.742162] iwlwifi 0000:00:07.0: loaded PNVM version 97f4ce1a > [ 3.762211] iwlwifi 0000:00:07.0: Detected RF FM, rfid=0x112200 > [ 3.854811] iwlwifi 0000:00:07.0: base HW address: 44:a3:bb:8d:9d:98 > [ 3.947696] iwlwifi 0000:00:07.0 wls7f0: renamed from wlan0 > [ 5.057881] iwlwifi 0000:00:07.0: Registered PHC clock: iwlwifi-PTP, with index: 1 > [ 2947.459857] iwlwifi 0000:00:07.0: Unregistering PHC clock: iwlwifi-PTP, with index: 1 > [ 2948.154855] iwlwifi 0000:00:07.0: Detected crf-id 0x2001910, cnv-id 0x2001910 wfpm id 0x80000000 > [ 2948.154955] iwlwifi 0000:00:07.0: PCI dev 272b/00f4, rev=0x472, rfid=0x112200 > [ 2948.154967] iwlwifi 0000:00:07.0: Detected Intel(R) Wi-Fi 7 BE200 320MHz > [ 2948.231903] iwlwifi 0000:00:07.0: TLV_FW_FSEQ_VERSION: FSEQ Version: 0.0.4.191 > [ 2948.232866] iwlwifi 0000:00:07.0: loaded firmware version 94.62990553.0 gl-c0-fm-c0-94.ucode op_mode iwlmvm > [ 2948.259195] ? iwl_pcie_rx_alloc+0x6f/0x300 [iwlwifi] > [ 2948.259231] ? iwl_pcie_rx_alloc+0x6f/0x300 [iwlwifi] > [ 2948.259245] iwl_pcie_rx_alloc+0x6f/0x300 [iwlwifi] > [ 2948.259259] _iwl_pcie_rx_init+0x34c/0x370 [iwlwifi] > [ 2948.259305] iwl_trans_pcie_gen2_start_fw+0x2ab/0x5f0 [iwlwifi] > [ 2948.259326] iwl_trans_start_fw+0x41/0x60 [iwlwifi] > [ 2948.259381] ? _iwl_dbg_tlv_time_point+0x19d/0x200 [iwlwifi] > [ 2948.259449] ? iwl_pcie_check_hw_rf_kill+0x21/0x90 [iwlwifi] > [ 2948.259515] _iwl_op_mode_start+0xa7/0xd0 [iwlwifi] > [ 2948.259530] iwl_req_fw_callback+0x78b/0xab0 [iwlwifi] > [ 2948.260724] iwlwifi 0000:00:07.0: Unable to init nic > [ 2948.260741] iwlwifi 0000:00:07.0: Failed to start RT ucode: -12 > [ 2948.260764] iwlwifi 0000:00:07.0: WRT: Collecting data: ini trigger 13 fired (delay=0ms). > [ 2948.510631] iwlwifi 0000:00:07.0: Start IWL Error Log Dump: > [ 2948.510656] iwlwifi 0000:00:07.0: Transport status: 0x00000042, valid: 6 > [ 2948.510674] iwlwifi 0000:00:07.0: Loaded firmware version: 94.62990553.0 gl-c0-fm-c0-94.ucode > [ 2948.510697] iwlwifi 0000:00:07.0: 0x00000084 | NMI_INTERRUPT_UNKNOWN > [ 2948.510714] iwlwifi 0000:00:07.0: 0x000002F0 | trm_hw_status0 > [ 2948.510730] iwlwifi 0000:00:07.0: 0x00000000 | trm_hw_status1 > [ 2948.510752] iwlwifi 0000:00:07.0: 0x002C4996 | branchlink2 > [ 2948.510766] iwlwifi 0000:00:07.0: 0x00015F80 | interruptlink1 > [ 2948.510782] iwlwifi 0000:00:07.0: 0x00015F80 | interruptlink2 > [ 2948.510798] iwlwifi 0000:00:07.0: 0x00015C56 | data1 > [ 2948.510811] iwlwifi 0000:00:07.0: 0x01000000 | data2 > [ 2948.510825] iwlwifi 0000:00:07.0: 0x00000000 | data3 > [ 2948.510841] iwlwifi 0000:00:07.0: 0x00000000 | beacon time > [ 2948.510855] iwlwifi 0000:00:07.0: 0xAF590F54 | tsf low > [ 2948.510868] iwlwifi 0000:00:07.0: 0x00000000 | tsf hi > [ 2948.510882] iwlwifi 0000:00:07.0: 0x00000000 | time gp1 > [ 2948.510896] iwlwifi 0000:00:07.0: 0xAF57F299 | time gp2 > [ 2948.510909] iwlwifi 0000:00:07.0: 0x00000001 | uCode revision type > [ 2948.510925] iwlwifi 0000:00:07.0: 0x0000005E | uCode version major > [ 2948.510945] iwlwifi 0000:00:07.0: 0x62990553 | uCode version minor > [ 2948.510962] iwlwifi 0000:00:07.0: 0x00000472 | hw version > [ 2948.510975] iwlwifi 0000:00:07.0: 0x18C80002 | board version > [ 2948.510991] iwlwifi 0000:00:07.0: 0x8042FA00 | hcmd > [ 2948.511005] iwlwifi 0000:00:07.0: 0x00020000 | isr0 > [ 2948.511018] iwlwifi 0000:00:07.0: 0x20000000 | isr1 > [ 2948.511035] iwlwifi 0000:00:07.0: 0x58F04082 | isr2 > [ 2948.511049] iwlwifi 0000:00:07.0: 0x00C0000C | isr3 > [ 2948.511062] iwlwifi 0000:00:07.0: 0x02000000 | isr4 > [ 2948.511075] iwlwifi 0000:00:07.0: 0x00E60103 | last cmd Id > [ 2948.511089] iwlwifi 0000:00:07.0: 0x00015C56 | wait_event > [ 2948.511106] iwlwifi 0000:00:07.0: 0x10000004 | l2p_control > [ 2948.511119] iwlwifi 0000:00:07.0: 0x00000000 | l2p_duration > [ 2948.511132] iwlwifi 0000:00:07.0: 0x00000000 | l2p_mhvalid > [ 2948.511146] iwlwifi 0000:00:07.0: 0x00000000 | l2p_addr_match > [ 2948.511165] iwlwifi 0000:00:07.0: 0x0000002B | lmpm_pmg_sel > [ 2948.511178] iwlwifi 0000:00:07.0: 0x00000000 | timestamp > [ 2948.511191] iwlwifi 0000:00:07.0: 0x00003064 | flow_handler > [ 2948.511610] iwlwifi 0000:00:07.0: Start IWL Error Log Dump: > [ 2948.511626] iwlwifi 0000:00:07.0: Transport status: 0x00000042, valid: 6 > [ 2948.511643] iwlwifi 0000:00:07.0: Loaded firmware version: 94.62990553.0 gl-c0-fm-c0-94.ucode > [ 2948.511669] iwlwifi 0000:00:07.0: 0x00000084 | NMI_INTERRUPT_UNKNOWN > [ 2948.511685] iwlwifi 0000:00:07.0: 0x000002F0 | trm_hw_status0 > [ 2948.511728] iwlwifi 0000:00:07.0: 0x00000000 | trm_hw_status1 > [ 2948.511744] iwlwifi 0000:00:07.0: 0x002C4996 | branchlink2 > [ 2948.511758] iwlwifi 0000:00:07.0: 0x002B8CC8 | interruptlink1 > [ 2948.511777] iwlwifi 0000:00:07.0: 0x002B8CC8 | interruptlink2 > [ 2948.511793] iwlwifi 0000:00:07.0: 0x002A5B6E | data1 > [ 2948.511806] iwlwifi 0000:00:07.0: 0x01000000 | data2 > [ 2948.511821] iwlwifi 0000:00:07.0: 0x00000000 | data3 > [ 2948.511837] iwlwifi 0000:00:07.0: 0x00000000 | beacon time > [ 2948.511850] iwlwifi 0000:00:07.0: 0xAF590F54 | tsf low > [ 2948.511863] iwlwifi 0000:00:07.0: 0x00000000 | tsf hi > [ 2948.511877] iwlwifi 0000:00:07.0: 0x00000000 | time gp1 > [ 2948.511890] iwlwifi 0000:00:07.0: 0xAF57F29A | time gp2 > [ 2948.511904] iwlwifi 0000:00:07.0: 0x00000001 | uCode revision type > [ 2948.511922] iwlwifi 0000:00:07.0: 0x0000005E | uCode version major > [ 2948.511938] iwlwifi 0000:00:07.0: 0x62990553 | uCode version minor > [ 2948.511954] iwlwifi 0000:00:07.0: 0x00000472 | hw version > [ 2948.511968] iwlwifi 0000:00:07.0: 0x18C80002 | board version > [ 2948.511984] iwlwifi 0000:00:07.0: 0x8041F503 | hcmd > [ 2948.511997] iwlwifi 0000:00:07.0: 0x00020000 | isr0 > [ 2948.512014] iwlwifi 0000:00:07.0: 0x20000000 | isr1 > [ 2948.512027] iwlwifi 0000:00:07.0: 0x58F00082 | isr2 > [ 2948.512040] iwlwifi 0000:00:07.0: 0x00C0000C | isr3 > [ 2948.512053] iwlwifi 0000:00:07.0: 0x02000000 | isr4 > [ 2948.512067] iwlwifi 0000:00:07.0: 0x00000000 | last cmd Id > [ 2948.512080] iwlwifi 0000:00:07.0: 0x002A5B6E | wait_event > [ 2948.512093] iwlwifi 0000:00:07.0: 0x10000004 | l2p_control > [ 2948.512107] iwlwifi 0000:00:07.0: 0x00000000 | l2p_duration > [ 2948.512120] iwlwifi 0000:00:07.0: 0x00000000 | l2p_mhvalid > [ 2948.512135] iwlwifi 0000:00:07.0: 0x00000000 | l2p_addr_match > [ 2948.512151] iwlwifi 0000:00:07.0: 0x00000028 | lmpm_pmg_sel > [ 2948.512165] iwlwifi 0000:00:07.0: 0x00000000 | timestamp > [ 2948.512178] iwlwifi 0000:00:07.0: 0x00003064 | flow_handler > [ 2948.512289] iwlwifi 0000:00:07.0: Start IWL Error Log Dump: > [ 2948.512305] iwlwifi 0000:00:07.0: Transport status: 0x00000042, valid: 7 > [ 2948.512321] iwlwifi 0000:00:07.0: 0x20000074 | ADVANCED_SYSASSERT > [ 2948.512341] iwlwifi 0000:00:07.0: 0x00000000 | umac branchlink1 > [ 2948.512358] iwlwifi 0000:00:07.0: 0xC008089A | umac branchlink2 > [ 2948.512377] iwlwifi 0000:00:07.0: 0x8028A292 | umac interruptlink1 > [ 2948.512393] iwlwifi 0000:00:07.0: 0x01077154 | umac interruptlink2 > [ 2948.512410] iwlwifi 0000:00:07.0: 0x01000000 | umac data1 > [ 2948.512426] iwlwifi 0000:00:07.0: 0x01077154 | umac data2 > [ 2948.512439] iwlwifi 0000:00:07.0: 0x00000000 | umac data3 > [ 2948.512453] iwlwifi 0000:00:07.0: 0x0000005E | umac major > [ 2948.512478] iwlwifi 0000:00:07.0: 0x62990553 | umac minor > [ 2948.512492] iwlwifi 0000:00:07.0: 0xAF57F28F | frame pointer > [ 2948.512508] iwlwifi 0000:00:07.0: 0xD00D6258 | stack pointer > [ 2948.512527] iwlwifi 0000:00:07.0: 0x00EB0F07 | last host cmd > [ 2948.512543] iwlwifi 0000:00:07.0: 0x00000400 | isr status reg > [ 2948.512666] iwlwifi 0000:00:07.0: TCM1 status: > [ 2948.512682] iwlwifi 0000:00:07.0: 0x00000070 | error ID > [ 2948.512695] iwlwifi 0000:00:07.0: 0x00001A96 | tcm branchlink2 > [ 2948.512714] iwlwifi 0000:00:07.0: 0x00001E38 | tcm interruptlink1 > [ 2948.512731] iwlwifi 0000:00:07.0: 0x00001E38 | tcm interruptlink2 > [ 2948.512750] iwlwifi 0000:00:07.0: 0x40000000 | tcm data1 > [ 2948.512764] iwlwifi 0000:00:07.0: 0xDEADBEEF | tcm data2 > [ 2948.512778] iwlwifi 0000:00:07.0: 0xDEADBEEF | tcm data3 > [ 2948.512794] iwlwifi 0000:00:07.0: 0x00001AF4 | tcm log PC > [ 2948.512807] iwlwifi 0000:00:07.0: 0x00803FF0 | tcm frame pointer > [ 2948.512823] iwlwifi 0000:00:07.0: 0x00803F5C | tcm stack pointer > [ 2948.512840] iwlwifi 0000:00:07.0: 0x00000000 | tcm msg ID > [ 2948.512856] iwlwifi 0000:00:07.0: 0x40000000 | tcm ISR status > [ 2948.512872] iwlwifi 0000:00:07.0: 0x000002F0 | tcm HW status[0] > [ 2948.512888] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[1] > [ 2948.512904] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[2] > [ 2948.512920] iwlwifi 0000:00:07.0: 0x00008100 | tcm HW status[3] > [ 2948.512936] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[4] > [ 2948.512952] iwlwifi 0000:00:07.0: 0x00000000 | tcm SW status[0] > [ 2948.513073] iwlwifi 0000:00:07.0: RCM1 status: > [ 2948.513086] iwlwifi 0000:00:07.0: 0x00000070 | error ID > [ 2948.513099] iwlwifi 0000:00:07.0: 0x00001AF2 | rcm branchlink2 > [ 2948.513115] iwlwifi 0000:00:07.0: 0x00002468 | rcm interruptlink1 > [ 2948.513131] iwlwifi 0000:00:07.0: 0x00002468 | rcm interruptlink2 > [ 2948.513147] iwlwifi 0000:00:07.0: 0x20000000 | rcm data1 > [ 2948.513160] iwlwifi 0000:00:07.0: 0xDEADBEEF | rcm data2 > [ 2948.513173] iwlwifi 0000:00:07.0: 0xDEADBEEF | rcm data3 > [ 2948.513187] iwlwifi 0000:00:07.0: 0x00001B4C | rcm log PC > [ 2948.513200] iwlwifi 0000:00:07.0: 0x00803FF0 | rcm frame pointer > [ 2948.513216] iwlwifi 0000:00:07.0: 0x00803F5C | rcm stack pointer > [ 2948.513232] iwlwifi 0000:00:07.0: 0x00000000 | rcm msg ID > [ 2948.513245] iwlwifi 0000:00:07.0: 0x20000000 | rcm ISR status > [ 2948.513261] iwlwifi 0000:00:07.0: 0x00020400 | frame HW status > [ 2948.513277] iwlwifi 0000:00:07.0: 0x00000000 | LMAC-to-RCM request mbox > [ 2948.513293] iwlwifi 0000:00:07.0: 0x00000000 | RCM-to-LMAC request mbox > [ 2948.513310] iwlwifi 0000:00:07.0: 0x00000000 | MAC header control > [ 2948.513326] iwlwifi 0000:00:07.0: 0x00000000 | MAC header addr1 low > [ 2948.513342] iwlwifi 0000:00:07.0: 0x003C0000 | MAC header info > [ 2948.513358] iwlwifi 0000:00:07.0: 0x00000000 | MAC header error > [ 2948.513573] iwlwifi 0000:00:07.0: TCM2 status: > [ 2948.513587] iwlwifi 0000:00:07.0: 0x00000070 | error ID > [ 2948.513600] iwlwifi 0000:00:07.0: 0x00001A96 | tcm branchlink2 > [ 2948.513616] iwlwifi 0000:00:07.0: 0x00001E38 | tcm interruptlink1 > [ 2948.653141] iwlwifi 0000:00:07.0: 0x00001E38 | tcm interruptlink2 > [ 2948.653168] iwlwifi 0000:00:07.0: 0x40000000 | tcm data1 > [ 2948.653186] iwlwifi 0000:00:07.0: 0xDEADBEEF | tcm data2 > [ 2948.653200] iwlwifi 0000:00:07.0: 0xDEADBEEF | tcm data3 > [ 2948.653216] iwlwifi 0000:00:07.0: 0x00001AF4 | tcm log PC > [ 2948.653230] iwlwifi 0000:00:07.0: 0x00803FF0 | tcm frame pointer > [ 2948.653248] iwlwifi 0000:00:07.0: 0x00803F5C | tcm stack pointer > [ 2948.653265] iwlwifi 0000:00:07.0: 0x00000000 | tcm msg ID > [ 2948.653281] iwlwifi 0000:00:07.0: 0x40000000 | tcm ISR status > [ 2948.653297] iwlwifi 0000:00:07.0: 0x000002F0 | tcm HW status[0] > [ 2948.653316] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[1] > [ 2948.653332] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[2] > [ 2948.653352] iwlwifi 0000:00:07.0: 0x00008000 | tcm HW status[3] > [ 2948.653368] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[4] > [ 2948.653386] iwlwifi 0000:00:07.0: 0x00000000 | tcm SW status[0] > [ 2948.653608] iwlwifi 0000:00:07.0: RCM2 status: > [ 2948.653625] iwlwifi 0000:00:07.0: 0x00000070 | error ID > [ 2948.653641] iwlwifi 0000:00:07.0: 0x00001AF2 | rcm branchlink2 > [ 2948.653660] iwlwifi 0000:00:07.0: 0x00002468 | rcm interruptlink1 > [ 2948.653678] iwlwifi 0000:00:07.0: 0x00002468 | rcm interruptlink2 > [ 2948.653697] iwlwifi 0000:00:07.0: 0x20000000 | rcm data1 > [ 2948.653710] iwlwifi 0000:00:07.0: 0xDEADBEEF | rcm data2 > [ 2948.653724] iwlwifi 0000:00:07.0: 0xDEADBEEF | rcm data3 > [ 2948.653740] iwlwifi 0000:00:07.0: 0x00001B4C | rcm log PC > [ 2948.653754] iwlwifi 0000:00:07.0: 0x00803FF0 | rcm frame pointer > [ 2948.653773] iwlwifi 0000:00:07.0: 0x00803F5C | rcm stack pointer > [ 2948.653789] iwlwifi 0000:00:07.0: 0x00000000 | rcm msg ID > [ 2948.653805] iwlwifi 0000:00:07.0: 0x20000000 | rcm ISR status > [ 2948.653825] iwlwifi 0000:00:07.0: 0x00020400 | frame HW status > [ 2948.653841] iwlwifi 0000:00:07.0: 0x00000000 | LMAC-to-RCM request mbox > [ 2948.653860] iwlwifi 0000:00:07.0: 0x00000000 | RCM-to-LMAC request mbox > [ 2948.653877] iwlwifi 0000:00:07.0: 0x00000000 | MAC header control > [ 2948.653893] iwlwifi 0000:00:07.0: 0x00000000 | MAC header addr1 low > [ 2948.653912] iwlwifi 0000:00:07.0: 0x003C0000 | MAC header info > [ 2948.653930] iwlwifi 0000:00:07.0: 0x00000000 | MAC header error > [ 2948.654030] iwlwifi 0000:00:07.0: IML/ROM dump: > [ 2948.654046] iwlwifi 0000:00:07.0: 0x00000000 | IML/ROM error/state > [ 2948.654225] iwlwifi 0000:00:07.0: 0x00000000 | IML/ROM data1 > [ 2948.654326] iwlwifi 0000:00:07.0: 0x00000080 | IML/ROM WFPM_AUTH_KEY_0 > [ 2948.654424] iwlwifi 0000:00:07.0: Fseq Registers: > [ 2948.654526] iwlwifi 0000:00:07.0: 0x60000A00 | FSEQ_ERROR_CODE > [ 2948.654623] iwlwifi 0000:00:07.0: 0x80B00004 | FSEQ_TOP_INIT_VERSION > [ 2948.654759] iwlwifi 0000:00:07.0: 0x00570000 | FSEQ_CNVIO_INIT_VERSION > [ 2948.654851] iwlwifi 0000:00:07.0: 0x0000AA14 | FSEQ_OTP_VERSION > [ 2948.654943] iwlwifi 0000:00:07.0: 0x0000000F | FSEQ_TOP_CONTENT_VERSION > [ 2948.655033] iwlwifi 0000:00:07.0: 0x4552414E | FSEQ_ALIVE_TOKEN > [ 2948.655126] iwlwifi 0000:00:07.0: 0x02001910 | FSEQ_CNVI_ID > [ 2948.655214] iwlwifi 0000:00:07.0: 0x02001910 | FSEQ_CNVR_ID > [ 2948.655335] iwlwifi 0000:00:07.0: 0x02001910 | CNVI_AUX_MISC_CHIP > [ 2948.655428] iwlwifi 0000:00:07.0: 0x02001910 | CNVR_AUX_MISC_CHIP > [ 2948.655535] iwlwifi 0000:00:07.0: 0x8F0F1041 | CNVR_SCU_SD_REGS_SD_REG_DIG_DCDC_VTRIM > [ 2948.655634] iwlwifi 0000:00:07.0: 0x00000000 | CNVR_SCU_SD_REGS_SD_REG_ACTIVE_VDIG_MIRROR > [ 2948.655730] iwlwifi 0000:00:07.0: 0x00570000 | FSEQ_PREV_CNVIO_INIT_VERSION > [ 2948.655822] iwlwifi 0000:00:07.0: 0x00B10005 | FSEQ_WIFI_FSEQ_VERSION > [ 2948.655914] iwlwifi 0000:00:07.0: 0x00B10005 | FSEQ_BT_FSEQ_VERSION > [ 2948.656004] iwlwifi 0000:00:07.0: 0x000000F0 | FSEQ_CLASS_TP_VERSION > [ 2948.656217] iwlwifi 0000:00:07.0: UMAC CURRENT PC: 0x1110bad > [ 2948.656311] iwlwifi 0000:00:07.0: LMAC1 CURRENT PC: 0x0 > [ 2948.656398] iwlwifi 0000:00:07.0: LMAC2 CURRENT PC: 0x0 > [ 2948.656497] iwlwifi 0000:00:07.0: UMAC CURRENT PC 1: 0x2220bad > [ 2948.656588] iwlwifi 0000:00:07.0: TCM1 CURRENT PC: 0x0 > [ 2948.656675] iwlwifi 0000:00:07.0: RCM1 CURRENT PC: 0x0 > [ 2948.656763] iwlwifi 0000:00:07.0: RCM2 CURRENT PC: 0x0 > [ 2948.656851] iwlwifi 0000:00:07.0: Function Scratch status: > [ 2948.656864] iwlwifi 0000:00:07.0: 0x01010000 | Func Scratch > [ 2949.329779] iwlwifi 0000:00:07.0: Failed to run INIT ucode: -12 > [ 2949.383110] iwlwifi 0000:00:07.0: retry init count 0 > [ 2949.408845] iwlwifi 0000:00:07.0: Unable to init nic > [ 2949.408870] iwlwifi 0000:00:07.0: Failed to start RT ucode: -12 > [ 2949.408890] iwlwifi 0000:00:07.0: WRT: Collecting data: ini trigger 13 fired (delay=0ms). > [ 2949.659633] iwlwifi 0000:00:07.0: Start IWL Error Log Dump: > [ 2949.659659] iwlwifi 0000:00:07.0: Transport status: 0x00000042, valid: 6 > [ 2949.659677] iwlwifi 0000:00:07.0: Loaded firmware version: 94.62990553.0 gl-c0-fm-c0-94.ucode > [ 2949.659699] iwlwifi 0000:00:07.0: 0x00000084 | NMI_INTERRUPT_UNKNOWN > [ 2949.659716] iwlwifi 0000:00:07.0: 0x000002F0 | trm_hw_status0 > [ 2949.659733] iwlwifi 0000:00:07.0: 0x00000000 | trm_hw_status1 > [ 2949.659756] iwlwifi 0000:00:07.0: 0x002C4996 | branchlink2 > [ 2949.659770] iwlwifi 0000:00:07.0: 0x00015F80 | interruptlink1 > [ 2949.659786] iwlwifi 0000:00:07.0: 0x00015F80 | interruptlink2 > [ 2949.659803] iwlwifi 0000:00:07.0: 0x00015C56 | data1 > [ 2949.659817] iwlwifi 0000:00:07.0: 0x01000000 | data2 > [ 2949.659830] iwlwifi 0000:00:07.0: 0x00000000 | data3 > [ 2949.659844] iwlwifi 0000:00:07.0: 0x00000000 | beacon time > [ 2949.659857] iwlwifi 0000:00:07.0: 0xAF590F54 | tsf low > [ 2949.659871] iwlwifi 0000:00:07.0: 0x00000000 | tsf hi > [ 2949.659888] iwlwifi 0000:00:07.0: 0x00000000 | time gp1 > [ 2949.659911] iwlwifi 0000:00:07.0: 0xAF57F299 | time gp2 > [ 2949.659925] iwlwifi 0000:00:07.0: 0x00000001 | uCode revision type > [ 2949.659960] iwlwifi 0000:00:07.0: 0x0000005E | uCode version major > [ 2949.659980] iwlwifi 0000:00:07.0: 0x62990553 | uCode version minor > [ 2949.660005] iwlwifi 0000:00:07.0: 0x00000472 | hw version > [ 2949.660022] iwlwifi 0000:00:07.0: 0x18C80002 | board version > [ 2949.660039] iwlwifi 0000:00:07.0: 0x8042FA00 | hcmd > [ 2949.660055] iwlwifi 0000:00:07.0: 0x00020000 | isr0 > [ 2949.660069] iwlwifi 0000:00:07.0: 0x20000000 | isr1 > [ 2949.660086] iwlwifi 0000:00:07.0: 0x58F04082 | isr2 > [ 2949.660099] iwlwifi 0000:00:07.0: 0x00C0000C | isr3 > [ 2949.660116] iwlwifi 0000:00:07.0: 0x02000000 | isr4 > [ 2949.660129] iwlwifi 0000:00:07.0: 0x00E60103 | last cmd Id > [ 2949.660143] iwlwifi 0000:00:07.0: 0x00015C56 | wait_event > [ 2949.660158] iwlwifi 0000:00:07.0: 0x10000004 | l2p_control > [ 2949.660172] iwlwifi 0000:00:07.0: 0x00000000 | l2p_duration > [ 2949.660188] iwlwifi 0000:00:07.0: 0x00000000 | l2p_mhvalid > [ 2949.660202] iwlwifi 0000:00:07.0: 0x00000000 | l2p_addr_match > [ 2949.660221] iwlwifi 0000:00:07.0: 0x0000002B | lmpm_pmg_sel > [ 2949.660235] iwlwifi 0000:00:07.0: 0x00000000 | timestamp > [ 2949.660251] iwlwifi 0000:00:07.0: 0x00003064 | flow_handler > [ 2949.660394] iwlwifi 0000:00:07.0: Start IWL Error Log Dump: > [ 2949.660410] iwlwifi 0000:00:07.0: Transport status: 0x00000042, valid: 6 > [ 2949.660427] iwlwifi 0000:00:07.0: Loaded firmware version: 94.62990553.0 gl-c0-fm-c0-94.ucode > [ 2949.660450] iwlwifi 0000:00:07.0: 0x00000084 | NMI_INTERRUPT_UNKNOWN > [ 2949.660486] iwlwifi 0000:00:07.0: 0x000002F0 | trm_hw_status0 > [ 2949.660508] iwlwifi 0000:00:07.0: 0x00000000 | trm_hw_status1 > [ 2949.660524] iwlwifi 0000:00:07.0: 0x002C4996 | branchlink2 > [ 2949.660540] iwlwifi 0000:00:07.0: 0x002B8CC8 | interruptlink1 > [ 2949.660557] iwlwifi 0000:00:07.0: 0x002B8CC8 | interruptlink2 > [ 2949.660576] iwlwifi 0000:00:07.0: 0x002A5B6E | data1 > [ 2949.660590] iwlwifi 0000:00:07.0: 0x01000000 | data2 > [ 2949.660607] iwlwifi 0000:00:07.0: 0x00000000 | data3 > [ 2949.660620] iwlwifi 0000:00:07.0: 0x00000000 | beacon time > [ 2949.660636] iwlwifi 0000:00:07.0: 0xAF590F54 | tsf low > [ 2949.660649] iwlwifi 0000:00:07.0: 0x00000000 | tsf hi > [ 2949.660665] iwlwifi 0000:00:07.0: 0x00000000 | time gp1 > [ 2949.660678] iwlwifi 0000:00:07.0: 0xAF57F29A | time gp2 > [ 2949.660692] iwlwifi 0000:00:07.0: 0x00000001 | uCode revision type > [ 2949.660711] iwlwifi 0000:00:07.0: 0x0000005E | uCode version major > [ 2949.660757] iwlwifi 0000:00:07.0: 0x62990553 | uCode version minor > [ 2949.660774] iwlwifi 0000:00:07.0: 0x00000472 | hw version > [ 2949.660820] iwlwifi 0000:00:07.0: 0x18C80002 | board version > [ 2949.660839] iwlwifi 0000:00:07.0: 0x8041F503 | hcmd > [ 2949.660853] iwlwifi 0000:00:07.0: 0x00020000 | isr0 > [ 2949.660869] iwlwifi 0000:00:07.0: 0x20000000 | isr1 > [ 2949.660883] iwlwifi 0000:00:07.0: 0x58F00082 | isr2 > [ 2949.660900] iwlwifi 0000:00:07.0: 0x00C0000C | isr3 > [ 2949.660922] iwlwifi 0000:00:07.0: 0x02000000 | isr4 > [ 2949.660939] iwlwifi 0000:00:07.0: 0x00000000 | last cmd Id > [ 2949.660952] iwlwifi 0000:00:07.0: 0x002A5B6E | wait_event > [ 2949.660966] iwlwifi 0000:00:07.0: 0x10000004 | l2p_control > [ 2949.660982] iwlwifi 0000:00:07.0: 0x00000000 | l2p_duration > [ 2949.660996] iwlwifi 0000:00:07.0: 0x00000000 | l2p_mhvalid > [ 2949.661009] iwlwifi 0000:00:07.0: 0x00000000 | l2p_addr_match > [ 2949.661035] iwlwifi 0000:00:07.0: 0x00000028 | lmpm_pmg_sel > [ 2949.661049] iwlwifi 0000:00:07.0: 0x00000000 | timestamp > [ 2949.661062] iwlwifi 0000:00:07.0: 0x00003064 | flow_handler > [ 2949.661243] iwlwifi 0000:00:07.0: Start IWL Error Log Dump: > [ 2949.661265] iwlwifi 0000:00:07.0: Transport status: 0x00000042, valid: 7 > [ 2949.661291] iwlwifi 0000:00:07.0: 0x20000074 | ADVANCED_SYSASSERT > [ 2949.661308] iwlwifi 0000:00:07.0: 0x00000000 | umac branchlink1 > [ 2949.661325] iwlwifi 0000:00:07.0: 0xC008089A | umac branchlink2 > [ 2949.661341] iwlwifi 0000:00:07.0: 0x8028A292 | umac interruptlink1 > [ 2949.661357] iwlwifi 0000:00:07.0: 0x01077154 | umac interruptlink2 > [ 2949.661373] iwlwifi 0000:00:07.0: 0x01000000 | umac data1 > [ 2949.661387] iwlwifi 0000:00:07.0: 0x01077154 | umac data2 > [ 2949.661400] iwlwifi 0000:00:07.0: 0x00000000 | umac data3 > [ 2949.661413] iwlwifi 0000:00:07.0: 0x0000005E | umac major > [ 2949.661426] iwlwifi 0000:00:07.0: 0x62990553 | umac minor > [ 2949.661439] iwlwifi 0000:00:07.0: 0xAF57F28F | frame pointer > [ 2949.661455] iwlwifi 0000:00:07.0: 0xD00D6258 | stack pointer > [ 2949.661498] iwlwifi 0000:00:07.0: 0x00EB0F07 | last host cmd > [ 2949.661515] iwlwifi 0000:00:07.0: 0x00000400 | isr status reg > [ 2949.661649] iwlwifi 0000:00:07.0: TCM1 status: > [ 2949.661663] iwlwifi 0000:00:07.0: 0x00000070 | error ID > [ 2949.661676] iwlwifi 0000:00:07.0: 0x00001A96 | tcm branchlink2 > [ 2949.661692] iwlwifi 0000:00:07.0: 0x00001E38 | tcm interruptlink1 > [ 2949.661709] iwlwifi 0000:00:07.0: 0x00001E38 | tcm interruptlink2 > [ 2949.661725] iwlwifi 0000:00:07.0: 0x40000000 | tcm data1 > [ 2949.661738] iwlwifi 0000:00:07.0: 0xDEADBEEF | tcm data2 > [ 2949.661751] iwlwifi 0000:00:07.0: 0xDEADBEEF | tcm data3 > [ 2949.661765] iwlwifi 0000:00:07.0: 0x00001AF4 | tcm log PC > [ 2949.661778] iwlwifi 0000:00:07.0: 0x00803FF0 | tcm frame pointer > [ 2949.661794] iwlwifi 0000:00:07.0: 0x00803F5C | tcm stack pointer > [ 2949.661810] iwlwifi 0000:00:07.0: 0x00000000 | tcm msg ID > [ 2949.661823] iwlwifi 0000:00:07.0: 0x40000000 | tcm ISR status > [ 2949.860316] iwlwifi 0000:00:07.0: 0x000002F0 | tcm HW status[0] > [ 2949.860344] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[1] > [ 2949.860368] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[2] > [ 2949.860387] iwlwifi 0000:00:07.0: 0x00008100 | tcm HW status[3] > [ 2949.860404] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[4] > [ 2949.860424] iwlwifi 0000:00:07.0: 0x00000000 | tcm SW status[0] > [ 2949.860635] iwlwifi 0000:00:07.0: RCM1 status: > [ 2949.860651] iwlwifi 0000:00:07.0: 0x00000070 | error ID > [ 2949.860668] iwlwifi 0000:00:07.0: 0x00001AF2 | rcm branchlink2 > [ 2949.860684] iwlwifi 0000:00:07.0: 0x00002468 | rcm interruptlink1 > [ 2949.860703] iwlwifi 0000:00:07.0: 0x00002468 | rcm interruptlink2 > [ 2949.860720] iwlwifi 0000:00:07.0: 0x20000000 | rcm data1 > [ 2949.860736] iwlwifi 0000:00:07.0: 0xDEADBEEF | rcm data2 > [ 2949.860749] iwlwifi 0000:00:07.0: 0xDEADBEEF | rcm data3 > [ 2949.860766] iwlwifi 0000:00:07.0: 0x00001B4C | rcm log PC > [ 2949.860779] iwlwifi 0000:00:07.0: 0x00803FF0 | rcm frame pointer > [ 2949.860798] iwlwifi 0000:00:07.0: 0x00803F5C | rcm stack pointer > [ 2949.860815] iwlwifi 0000:00:07.0: 0x00000000 | rcm msg ID > [ 2949.860831] iwlwifi 0000:00:07.0: 0x20000000 | rcm ISR status > [ 2949.860847] iwlwifi 0000:00:07.0: 0x00020400 | frame HW status > [ 2949.860866] iwlwifi 0000:00:07.0: 0x00000000 | LMAC-to-RCM request mbox > [ 2949.860883] iwlwifi 0000:00:07.0: 0x00000000 | RCM-to-LMAC request mbox > [ 2949.860902] iwlwifi 0000:00:07.0: 0x00000000 | MAC header control > [ 2949.860918] iwlwifi 0000:00:07.0: 0x00000000 | MAC header addr1 low > [ 2949.860938] iwlwifi 0000:00:07.0: 0x003C0000 | MAC header info > [ 2949.860954] iwlwifi 0000:00:07.0: 0x00000000 | MAC header error > [ 2949.861081] iwlwifi 0000:00:07.0: TCM2 status: > [ 2949.861096] iwlwifi 0000:00:07.0: 0x00000070 | error ID > [ 2949.861112] iwlwifi 0000:00:07.0: 0x00001A96 | tcm branchlink2 > [ 2949.861129] iwlwifi 0000:00:07.0: 0x00001E38 | tcm interruptlink1 > [ 2949.861148] iwlwifi 0000:00:07.0: 0x00001E38 | tcm interruptlink2 > [ 2949.861164] iwlwifi 0000:00:07.0: 0x40000000 | tcm data1 > [ 2949.861181] iwlwifi 0000:00:07.0: 0xDEADBEEF | tcm data2 > [ 2949.861194] iwlwifi 0000:00:07.0: 0xDEADBEEF | tcm data3 > [ 2949.861210] iwlwifi 0000:00:07.0: 0x00001AF4 | tcm log PC > [ 2949.861224] iwlwifi 0000:00:07.0: 0x00803FF0 | tcm frame pointer > [ 2949.861243] iwlwifi 0000:00:07.0: 0x00803F5C | tcm stack pointer > [ 2949.861259] iwlwifi 0000:00:07.0: 0x00000000 | tcm msg ID > [ 2949.861276] iwlwifi 0000:00:07.0: 0x40000000 | tcm ISR status > [ 2949.861292] iwlwifi 0000:00:07.0: 0x000002F0 | tcm HW status[0] > [ 2949.861312] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[1] > [ 2949.861328] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[2] > [ 2949.861348] iwlwifi 0000:00:07.0: 0x00008000 | tcm HW status[3] > [ 2949.861364] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[4] > [ 2949.861384] iwlwifi 0000:00:07.0: 0x00000000 | tcm SW status[0] > [ 2949.861609] iwlwifi 0000:00:07.0: RCM2 status: > [ 2949.861626] iwlwifi 0000:00:07.0: 0x00000070 | error ID > [ 2949.861639] iwlwifi 0000:00:07.0: 0x00001AF2 | rcm branchlink2 > [ 2949.861655] iwlwifi 0000:00:07.0: 0x00002468 | rcm interruptlink1 > [ 2949.861676] iwlwifi 0000:00:07.0: 0x00002468 | rcm interruptlink2 > [ 2949.861692] iwlwifi 0000:00:07.0: 0x20000000 | rcm data1 > [ 2949.861706] iwlwifi 0000:00:07.0: 0xDEADBEEF | rcm data2 > [ 2949.861719] iwlwifi 0000:00:07.0: 0xDEADBEEF | rcm data3 > [ 2949.861732] iwlwifi 0000:00:07.0: 0x00001B4C | rcm log PC > [ 2949.861746] iwlwifi 0000:00:07.0: 0x00803FF0 | rcm frame pointer > [ 2949.861762] iwlwifi 0000:00:07.0: 0x00803F5C | rcm stack pointer > [ 2949.861778] iwlwifi 0000:00:07.0: 0x00000000 | rcm msg ID > [ 2949.861792] iwlwifi 0000:00:07.0: 0x20000000 | rcm ISR status > [ 2949.861808] iwlwifi 0000:00:07.0: 0x00020400 | frame HW status > [ 2949.861824] iwlwifi 0000:00:07.0: 0x00000000 | LMAC-to-RCM request mbox > [ 2949.861841] iwlwifi 0000:00:07.0: 0x00000000 | RCM-to-LMAC request mbox > [ 2949.861857] iwlwifi 0000:00:07.0: 0x00000000 | MAC header control > [ 2949.861874] iwlwifi 0000:00:07.0: 0x00000000 | MAC header addr1 low > [ 2949.861890] iwlwifi 0000:00:07.0: 0x003C0000 | MAC header info > [ 2949.861906] iwlwifi 0000:00:07.0: 0x00000000 | MAC header error > [ 2949.862004] iwlwifi 0000:00:07.0: IML/ROM dump: > [ 2949.862019] iwlwifi 0000:00:07.0: 0x00000000 | IML/ROM error/state > [ 2949.862116] iwlwifi 0000:00:07.0: 0x00000000 | IML/ROM data1 > [ 2949.862214] iwlwifi 0000:00:07.0: 0x00000080 | IML/ROM WFPM_AUTH_KEY_0 > [ 2949.862309] iwlwifi 0000:00:07.0: Fseq Registers: > [ 2949.862397] iwlwifi 0000:00:07.0: 0x60000A00 | FSEQ_ERROR_CODE > [ 2949.862504] iwlwifi 0000:00:07.0: 0x80B00004 | FSEQ_TOP_INIT_VERSION > [ 2949.862598] iwlwifi 0000:00:07.0: 0x00570000 | FSEQ_CNVIO_INIT_VERSION > [ 2949.862690] iwlwifi 0000:00:07.0: 0x0000AA14 | FSEQ_OTP_VERSION > [ 2949.862782] iwlwifi 0000:00:07.0: 0x0000000F | FSEQ_TOP_CONTENT_VERSION > [ 2949.862874] iwlwifi 0000:00:07.0: 0x4552414E | FSEQ_ALIVE_TOKEN > [ 2949.862965] iwlwifi 0000:00:07.0: 0x02001910 | FSEQ_CNVI_ID > [ 2949.863074] iwlwifi 0000:00:07.0: 0x02001910 | FSEQ_CNVR_ID > [ 2949.863171] iwlwifi 0000:00:07.0: 0x02001910 | CNVI_AUX_MISC_CHIP > [ 2950.060343] iwlwifi 0000:00:07.0: 0x02001910 | CNVR_AUX_MISC_CHIP > [ 2950.060446] iwlwifi 0000:00:07.0: 0x8F0F1041 | CNVR_SCU_SD_REGS_SD_REG_DIG_DCDC_VTRIM > [ 2950.060560] iwlwifi 0000:00:07.0: 0x00000000 | CNVR_SCU_SD_REGS_SD_REG_ACTIVE_VDIG_MIRROR > [ 2950.060668] iwlwifi 0000:00:07.0: 0x00570000 | FSEQ_PREV_CNVIO_INIT_VERSION > [ 2950.060764] iwlwifi 0000:00:07.0: 0x00B10005 | FSEQ_WIFI_FSEQ_VERSION > [ 2950.060861] iwlwifi 0000:00:07.0: 0x00B10005 | FSEQ_BT_FSEQ_VERSION > [ 2950.060956] iwlwifi 0000:00:07.0: 0x000000F0 | FSEQ_CLASS_TP_VERSION > [ 2950.061369] iwlwifi 0000:00:07.0: UMAC CURRENT PC: 0x1110bad > [ 2950.061482] iwlwifi 0000:00:07.0: LMAC1 CURRENT PC: 0x0 > [ 2950.061576] iwlwifi 0000:00:07.0: LMAC2 CURRENT PC: 0x0 > [ 2950.061669] iwlwifi 0000:00:07.0: UMAC CURRENT PC 1: 0x2220bad > [ 2950.061774] iwlwifi 0000:00:07.0: TCM1 CURRENT PC: 0x0 > [ 2950.061865] iwlwifi 0000:00:07.0: RCM1 CURRENT PC: 0x0 > [ 2950.061966] iwlwifi 0000:00:07.0: RCM2 CURRENT PC: 0x0 > [ 2950.062169] iwlwifi 0000:00:07.0: Function Scratch status: > [ 2950.062187] iwlwifi 0000:00:07.0: 0x01010000 | Func Scratch > [ 2950.757054] iwlwifi 0000:00:07.0: Failed to run INIT ucode: -12 > [ 2950.805512] iwlwifi 0000:00:07.0: retry init count 1 > [ 2950.979841] iwlwifi 0000:00:07.0: Unable to init nic > [ 2950.979885] iwlwifi 0000:00:07.0: Failed to start RT ucode: -12 > [ 2950.979908] iwlwifi 0000:00:07.0: WRT: Collecting data: ini trigger 13 fired (delay=0ms). > [ 2951.230434] iwlwifi 0000:00:07.0: Start IWL Error Log Dump: > [ 2951.230473] iwlwifi 0000:00:07.0: Transport status: 0x00000042, valid: 6 > [ 2951.230492] iwlwifi 0000:00:07.0: Loaded firmware version: 94.62990553.0 gl-c0-fm-c0-94.ucode > [ 2951.230516] iwlwifi 0000:00:07.0: 0x00000084 | NMI_INTERRUPT_UNKNOWN > [ 2951.230533] iwlwifi 0000:00:07.0: 0x000002F0 | trm_hw_status0 > [ 2951.230550] iwlwifi 0000:00:07.0: 0x00000000 | trm_hw_status1 > [ 2951.230566] iwlwifi 0000:00:07.0: 0x002C4996 | branchlink2 > [ 2951.230580] iwlwifi 0000:00:07.0: 0x00015F80 | interruptlink1 > [ 2951.230607] iwlwifi 0000:00:07.0: 0x00015F80 | interruptlink2 > [ 2951.230623] iwlwifi 0000:00:07.0: 0x00015C56 | data1 > [ 2951.230637] iwlwifi 0000:00:07.0: 0x01000000 | data2 > [ 2951.230652] iwlwifi 0000:00:07.0: 0x00000000 | data3 > [ 2951.230666] iwlwifi 0000:00:07.0: 0x00000000 | beacon time > [ 2951.230679] iwlwifi 0000:00:07.0: 0xAF590F54 | tsf low > [ 2951.230693] iwlwifi 0000:00:07.0: 0x00000000 | tsf hi > [ 2951.230707] iwlwifi 0000:00:07.0: 0x00000000 | time gp1 > [ 2951.230721] iwlwifi 0000:00:07.0: 0xAF57F299 | time gp2 > [ 2951.230734] iwlwifi 0000:00:07.0: 0x00000001 | uCode revision type > [ 2951.230751] iwlwifi 0000:00:07.0: 0x0000005E | uCode version major > [ 2951.230768] iwlwifi 0000:00:07.0: 0x62990553 | uCode version minor > [ 2951.230784] iwlwifi 0000:00:07.0: 0x00000472 | hw version > [ 2951.230798] iwlwifi 0000:00:07.0: 0x18C80002 | board version > [ 2951.230815] iwlwifi 0000:00:07.0: 0x8042FA00 | hcmd > [ 2951.230829] iwlwifi 0000:00:07.0: 0x00020000 | isr0 > [ 2951.230842] iwlwifi 0000:00:07.0: 0x20000000 | isr1 > [ 2951.230856] iwlwifi 0000:00:07.0: 0x58F04082 | isr2 > [ 2951.230869] iwlwifi 0000:00:07.0: 0x00C0000C | isr3 > [ 2951.230883] iwlwifi 0000:00:07.0: 0x02000000 | isr4 > [ 2951.230902] iwlwifi 0000:00:07.0: 0x00E60103 | last cmd Id > [ 2951.230916] iwlwifi 0000:00:07.0: 0x00015C56 | wait_event > [ 2951.230930] iwlwifi 0000:00:07.0: 0x10000004 | l2p_control > [ 2951.230943] iwlwifi 0000:00:07.0: 0x00000000 | l2p_duration > [ 2951.230957] iwlwifi 0000:00:07.0: 0x00000000 | l2p_mhvalid > [ 2951.230970] iwlwifi 0000:00:07.0: 0x00000000 | l2p_addr_match > [ 2951.230986] iwlwifi 0000:00:07.0: 0x0000002B | lmpm_pmg_sel > [ 2951.230999] iwlwifi 0000:00:07.0: 0x00000000 | timestamp > [ 2951.231013] iwlwifi 0000:00:07.0: 0x00003064 | flow_handler > [ 2951.231154] iwlwifi 0000:00:07.0: Start IWL Error Log Dump: > [ 2951.231167] iwlwifi 0000:00:07.0: Transport status: 0x00000042, valid: 6 > [ 2951.231184] iwlwifi 0000:00:07.0: Loaded firmware version: 94.62990553.0 gl-c0-fm-c0-94.ucode > [ 2951.231206] iwlwifi 0000:00:07.0: 0x00000084 | NMI_INTERRUPT_UNKNOWN > [ 2951.231222] iwlwifi 0000:00:07.0: 0x000002F0 | trm_hw_status0 > [ 2951.231238] iwlwifi 0000:00:07.0: 0x00000000 | trm_hw_status1 > [ 2951.231254] iwlwifi 0000:00:07.0: 0x002C4996 | branchlink2 > [ 2951.231268] iwlwifi 0000:00:07.0: 0x002B8CC8 | interruptlink1 > [ 2951.231286] iwlwifi 0000:00:07.0: 0x002B8CC8 | interruptlink2 > [ 2951.231302] iwlwifi 0000:00:07.0: 0x002A5B6E | data1 > [ 2951.231316] iwlwifi 0000:00:07.0: 0x01000000 | data2 > [ 2951.231334] iwlwifi 0000:00:07.0: 0x00000000 | data3 > [ 2951.231348] iwlwifi 0000:00:07.0: 0x00000000 | beacon time > [ 2951.231361] iwlwifi 0000:00:07.0: 0xAF590F54 | tsf low > [ 2951.231374] iwlwifi 0000:00:07.0: 0x00000000 | tsf hi > [ 2951.231387] iwlwifi 0000:00:07.0: 0x00000000 | time gp1 > [ 2951.231401] iwlwifi 0000:00:07.0: 0xAF57F29A | time gp2 > [ 2951.231414] iwlwifi 0000:00:07.0: 0x00000001 | uCode revision type > [ 2951.231430] iwlwifi 0000:00:07.0: 0x0000005E | uCode version major > [ 2951.231446] iwlwifi 0000:00:07.0: 0x62990553 | uCode version minor > [ 2951.231470] iwlwifi 0000:00:07.0: 0x00000472 | hw version > [ 2951.231483] iwlwifi 0000:00:07.0: 0x18C80002 | board version > [ 2951.231521] iwlwifi 0000:00:07.0: 0x8041F503 | hcmd > [ 2951.231535] iwlwifi 0000:00:07.0: 0x00020000 | isr0 > [ 2951.231549] iwlwifi 0000:00:07.0: 0x20000000 | isr1 > [ 2951.231562] iwlwifi 0000:00:07.0: 0x58F00082 | isr2 > [ 2951.231575] iwlwifi 0000:00:07.0: 0x00C0000C | isr3 > [ 2951.231589] iwlwifi 0000:00:07.0: 0x02000000 | isr4 > [ 2951.231602] iwlwifi 0000:00:07.0: 0x00000000 | last cmd Id > [ 2951.231616] iwlwifi 0000:00:07.0: 0x002A5B6E | wait_event > [ 2951.231630] iwlwifi 0000:00:07.0: 0x10000004 | l2p_control > [ 2951.231643] iwlwifi 0000:00:07.0: 0x00000000 | l2p_duration > [ 2951.231657] iwlwifi 0000:00:07.0: 0x00000000 | l2p_mhvalid > [ 2951.231670] iwlwifi 0000:00:07.0: 0x00000000 | l2p_addr_match > [ 2951.231686] iwlwifi 0000:00:07.0: 0x00000028 | lmpm_pmg_sel > [ 2951.231700] iwlwifi 0000:00:07.0: 0x00000000 | timestamp > [ 2951.231713] iwlwifi 0000:00:07.0: 0x00003064 | flow_handler > [ 2951.231827] iwlwifi 0000:00:07.0: Start IWL Error Log Dump: > [ 2951.231841] iwlwifi 0000:00:07.0: Transport status: 0x00000042, valid: 7 > [ 2951.231857] iwlwifi 0000:00:07.0: 0x20000074 | ADVANCED_SYSASSERT > [ 2951.231874] iwlwifi 0000:00:07.0: 0x00000000 | umac branchlink1 > [ 2951.231890] iwlwifi 0000:00:07.0: 0xC008089A | umac branchlink2 > [ 2951.231906] iwlwifi 0000:00:07.0: 0x8028A292 | umac interruptlink1 > [ 2951.231922] iwlwifi 0000:00:07.0: 0x01077154 | umac interruptlink2 > [ 2951.231939] iwlwifi 0000:00:07.0: 0x01000000 | umac data1 > [ 2951.231952] iwlwifi 0000:00:07.0: 0x01077154 | umac data2 > [ 2951.231965] iwlwifi 0000:00:07.0: 0x00000000 | umac data3 > [ 2951.231979] iwlwifi 0000:00:07.0: 0x0000005E | umac major > [ 2951.231992] iwlwifi 0000:00:07.0: 0x62990553 | umac minor > [ 2951.232005] iwlwifi 0000:00:07.0: 0xAF57F28F | frame pointer > [ 2951.232022] iwlwifi 0000:00:07.0: 0xD00D6258 | stack pointer > [ 2951.232038] iwlwifi 0000:00:07.0: 0x00EB0F07 | last host cmd > [ 2951.232054] iwlwifi 0000:00:07.0: 0x00000400 | isr status reg > [ 2951.232175] iwlwifi 0000:00:07.0: TCM1 status: > [ 2951.232189] iwlwifi 0000:00:07.0: 0x00000070 | error ID > [ 2951.232202] iwlwifi 0000:00:07.0: 0x00001A96 | tcm branchlink2 > [ 2951.232218] iwlwifi 0000:00:07.0: 0x00001E38 | tcm interruptlink1 > [ 2951.232234] iwlwifi 0000:00:07.0: 0x00001E38 | tcm interruptlink2 > [ 2951.232250] iwlwifi 0000:00:07.0: 0x40000000 | tcm data1 > [ 2951.232264] iwlwifi 0000:00:07.0: 0xDEADBEEF | tcm data2 > [ 2951.232277] iwlwifi 0000:00:07.0: 0xDEADBEEF | tcm data3 > [ 2951.232290] iwlwifi 0000:00:07.0: 0x00001AF4 | tcm log PC > [ 2951.232304] iwlwifi 0000:00:07.0: 0x00803FF0 | tcm frame pointer > [ 2951.232320] iwlwifi 0000:00:07.0: 0x00803F5C | tcm stack pointer > [ 2951.232337] iwlwifi 0000:00:07.0: 0x00000000 | tcm msg ID > [ 2951.232350] iwlwifi 0000:00:07.0: 0x40000000 | tcm ISR status > [ 2951.232371] iwlwifi 0000:00:07.0: 0x000002F0 | tcm HW status[0] > [ 2951.232388] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[1] > [ 2951.232404] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[2] > [ 2951.232420] iwlwifi 0000:00:07.0: 0x00008100 | tcm HW status[3] > [ 2951.232437] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[4] > [ 2951.232453] iwlwifi 0000:00:07.0: 0x00000000 | tcm SW status[0] > [ 2951.232586] iwlwifi 0000:00:07.0: RCM1 status: > [ 2951.232600] iwlwifi 0000:00:07.0: 0x00000070 | error ID > [ 2951.232614] iwlwifi 0000:00:07.0: 0x00001AF2 | rcm branchlink2 > [ 2951.232630] iwlwifi 0000:00:07.0: 0x00002468 | rcm interruptlink1 > [ 2951.232646] iwlwifi 0000:00:07.0: 0x00002468 | rcm interruptlink2 > [ 2951.232662] iwlwifi 0000:00:07.0: 0x20000000 | rcm data1 > [ 2951.232675] iwlwifi 0000:00:07.0: 0xDEADBEEF | rcm data2 > [ 2951.232688] iwlwifi 0000:00:07.0: 0xDEADBEEF | rcm data3 > [ 2951.232701] iwlwifi 0000:00:07.0: 0x00001B4C | rcm log PC > [ 2951.232715] iwlwifi 0000:00:07.0: 0x00803FF0 | rcm frame pointer > [ 2951.232731] iwlwifi 0000:00:07.0: 0x00803F5C | rcm stack pointer > [ 2951.232747] iwlwifi 0000:00:07.0: 0x00000000 | rcm msg ID > [ 2951.232760] iwlwifi 0000:00:07.0: 0x20000000 | rcm ISR status > [ 2951.232776] iwlwifi 0000:00:07.0: 0x00020400 | frame HW status > [ 2951.232792] iwlwifi 0000:00:07.0: 0x00000000 | LMAC-to-RCM request mbox > [ 2951.232808] iwlwifi 0000:00:07.0: 0x00000000 | RCM-to-LMAC request mbox > [ 2951.232825] iwlwifi 0000:00:07.0: 0x00000000 | MAC header control > [ 2951.232842] iwlwifi 0000:00:07.0: 0x00000000 | MAC header addr1 low > [ 2951.232858] iwlwifi 0000:00:07.0: 0x003C0000 | MAC header info > [ 2951.232879] iwlwifi 0000:00:07.0: 0x00000000 | MAC header error > [ 2951.233000] iwlwifi 0000:00:07.0: TCM2 status: > [ 2951.233014] iwlwifi 0000:00:07.0: 0x00000070 | error ID > [ 2951.233027] iwlwifi 0000:00:07.0: 0x00001A96 | tcm branchlink2 > [ 2951.233044] iwlwifi 0000:00:07.0: 0x00001E38 | tcm interruptlink1 > [ 2951.233060] iwlwifi 0000:00:07.0: 0x00001E38 | tcm interruptlink2 > [ 2951.233076] iwlwifi 0000:00:07.0: 0x40000000 | tcm data1 > [ 2951.233090] iwlwifi 0000:00:07.0: 0xDEADBEEF | tcm data2 > [ 2951.233103] iwlwifi 0000:00:07.0: 0xDEADBEEF | tcm data3 > [ 2951.233117] iwlwifi 0000:00:07.0: 0x00001AF4 | tcm log PC > [ 2951.233130] iwlwifi 0000:00:07.0: 0x00803FF0 | tcm frame pointer > [ 2951.233147] iwlwifi 0000:00:07.0: 0x00803F5C | tcm stack pointer > [ 2951.233163] iwlwifi 0000:00:07.0: 0x00000000 | tcm msg ID > [ 2951.233177] iwlwifi 0000:00:07.0: 0x40000000 | tcm ISR status > [ 2951.233193] iwlwifi 0000:00:07.0: 0x000002F0 | tcm HW status[0] > [ 2951.233209] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[1] > [ 2951.233226] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[2] > [ 2951.233242] iwlwifi 0000:00:07.0: 0x00008000 | tcm HW status[3] > [ 2951.233259] iwlwifi 0000:00:07.0: 0x00000000 | tcm HW status[4] > [ 2951.233276] iwlwifi 0000:00:07.0: 0x00000000 | tcm SW status[0] > [ 2951.233397] iwlwifi 0000:00:07.0: RCM2 status: > [ 2951.233413] iwlwifi 0000:00:07.0: 0x00000070 | error ID > [ 2951.233433] iwlwifi 0000:00:07.0: 0x00001AF2 | rcm branchlink2 > [ 2951.233450] iwlwifi 0000:00:07.0: 0x00002468 | rcm interruptlink1 > [ 2951.233485] iwlwifi 0000:00:07.0: 0x00002468 | rcm interruptlink2 > [ 2951.233502] iwlwifi 0000:00:07.0: 0x20000000 | rcm data1 > [ 2951.233516] iwlwifi 0000:00:07.0: 0xDEADBEEF | rcm data2 > [ 2951.233529] iwlwifi 0000:00:07.0: 0xDEADBEEF | rcm data3 > [ 2951.233543] iwlwifi 0000:00:07.0: 0x00001B4C | rcm log PC > [ 2951.233556] iwlwifi 0000:00:07.0: 0x00803FF0 | rcm frame pointer > [ 2951.233572] iwlwifi 0000:00:07.0: 0x00803F5C | rcm stack pointer > [ 2951.233588] iwlwifi 0000:00:07.0: 0x00000000 | rcm msg ID > [ 2951.233601] iwlwifi 0000:00:07.0: 0x20000000 | rcm ISR status > [ 2951.233618] iwlwifi 0000:00:07.0: 0x00020400 | frame HW status > [ 2951.233634] iwlwifi 0000:00:07.0: 0x00000000 | LMAC-to-RCM request mbox > [ 2951.233650] iwlwifi 0000:00:07.0: 0x00000000 | RCM-to-LMAC request mbox > [ 2951.233666] iwlwifi 0000:00:07.0: 0x00000000 | MAC header control > [ 2951.233682] iwlwifi 0000:00:07.0: 0x00000000 | MAC header addr1 low > [ 2951.233699] iwlwifi 0000:00:07.0: 0x003C0000 | MAC header info > [ 2951.233715] iwlwifi 0000:00:07.0: 0x00000000 | MAC header error > [ 2951.233812] iwlwifi 0000:00:07.0: IML/ROM dump: > [ 2951.233826] iwlwifi 0000:00:07.0: 0x00000000 | IML/ROM error/state > [ 2951.233926] iwlwifi 0000:00:07.0: 0x00000000 | IML/ROM data1 > [ 2951.234150] iwlwifi 0000:00:07.0: 0x00000080 | IML/ROM WFPM_AUTH_KEY_0 > [ 2951.234251] iwlwifi 0000:00:07.0: Fseq Registers: > [ 2951.234339] iwlwifi 0000:00:07.0: 0x60000A00 | FSEQ_ERROR_CODE > [ 2951.234439] iwlwifi 0000:00:07.0: 0x80B00004 | FSEQ_TOP_INIT_VERSION > [ 2951.234547] iwlwifi 0000:00:07.0: 0x00570000 | FSEQ_CNVIO_INIT_VERSION > [ 2951.234645] iwlwifi 0000:00:07.0: 0x0000AA14 | FSEQ_OTP_VERSION > [ 2951.234745] iwlwifi 0000:00:07.0: 0x0000000F | FSEQ_TOP_CONTENT_VERSION > [ 2951.234840] iwlwifi 0000:00:07.0: 0x4552414E | FSEQ_ALIVE_TOKEN > [ 2951.234935] iwlwifi 0000:00:07.0: 0x02001910 | FSEQ_CNVI_ID > [ 2951.235036] iwlwifi 0000:00:07.0: 0x02001910 | FSEQ_CNVR_ID > [ 2951.235130] iwlwifi 0000:00:07.0: 0x02001910 | CNVI_AUX_MISC_CHIP > [ 2951.235229] iwlwifi 0000:00:07.0: 0x02001910 | CNVR_AUX_MISC_CHIP > [ 2951.235329] iwlwifi 0000:00:07.0: 0x00001041 | CNVR_SCU_SD_REGS_SD_REG_DIG_DCDC_VTRIM > [ 2951.235431] iwlwifi 0000:00:07.0: 0x00000000 | CNVR_SCU_SD_REGS_SD_REG_ACTIVE_VDIG_MIRROR > [ 2951.235544] iwlwifi 0000:00:07.0: 0x00570000 | FSEQ_PREV_CNVIO_INIT_VERSION > [ 2951.235642] iwlwifi 0000:00:07.0: 0x00B10005 | FSEQ_WIFI_FSEQ_VERSION > [ 2951.235738] iwlwifi 0000:00:07.0: 0x00B10005 | FSEQ_BT_FSEQ_VERSION > [ 2951.235834] iwlwifi 0000:00:07.0: 0x000000F0 | FSEQ_CLASS_TP_VERSION > [ 2951.235938] iwlwifi 0000:00:07.0: UMAC CURRENT PC: 0x1110bad > [ 2951.236065] iwlwifi 0000:00:07.0: LMAC1 CURRENT PC: 0x0 > [ 2951.236164] iwlwifi 0000:00:07.0: LMAC2 CURRENT PC: 0x0 > [ 2951.236265] iwlwifi 0000:00:07.0: UMAC CURRENT PC 1: 0x2220bad > [ 2951.236361] iwlwifi 0000:00:07.0: TCM1 CURRENT PC: 0x0 > [ 2951.236453] iwlwifi 0000:00:07.0: RCM1 CURRENT PC: 0x0 > [ 2951.236552] iwlwifi 0000:00:07.0: RCM2 CURRENT PC: 0x0 > [ 2951.236641] iwlwifi 0000:00:07.0: Function Scratch status: > [ 2951.236655] iwlwifi 0000:00:07.0: 0x01010000 | Func Scratch > [ 2951.903761] iwlwifi 0000:00:07.0: Failed to run INIT ucode: -12 > [ 2951.951941] iwlwifi 0000:00:07.0: retry init count 2 ``` </details> **sys-net# lspci -vvv -s 00:07.0** <details> ``` > 00:07.0 Network controller: Intel Corporation Wi-Fi 7(802.11be) AX1775*/AX1790*/BE20*/BE401/BE1750* 2x2 (rev 1a) > Subsystem: Intel Corporation BE200 320MHz [Gale Peak] > Physical Slot: 7 > Control: I/O- Mem+ BusMaster- SpecCycle- MemWINV- VGASnoop- ParErr- Stepping- SERR- FastB2B- DisINTx- > Status: Cap+ 66MHz- UDF- FastB2B- ParErr- DEVSEL=fast >TAbort- <TAbort- <MAbort- >SERR- <PERR- INTx- > Interrupt: pin A routed to IRQ 44 > Region 0: Memory at f2030000 (64-bit, non-prefetchable) [size=16K] > Capabilities: [40] Power Management version 3 > Flags: PMEClk- DSI- D1- D2- AuxCurrent=0mA PME(D0-,D1-,D2-,D3hot-,D3cold-) > Status: D0 NoSoftRst+ PME-Enable- DSel=0 DScale=0 PME- > Capabilities: [50] MSI: Enable- Count=1/1 Maskable- 64bit+ > Address: 0000000000000000 Data: 0000 > Capabilities: [70] Express (v2) Endpoint, IntMsgNum 0 > DevCap: MaxPayload 128 bytes, PhantFunc 0, Latency L0s unlimited, L1 unlimited > ExtTag- AttnBtn- AttnInd- PwrInd- RBE+ FLReset- SlotPowerLimit 10W TEE-IO- > DevCtl: CorrErr+ NonFatalErr+ FatalErr+ UnsupReq+ > RlxdOrd+ ExtTag- PhantFunc- AuxPwr- NoSnoop+ > MaxPayload 128 bytes, MaxReadReq 512 bytes > DevSta: CorrErr+ NonFatalErr- FatalErr- UnsupReq+ AuxPwr+ TransPend- > LnkCap: Port #0, Speed 16GT/s, Width x1, ASPM L1, Exit Latency L1 <64us > ClockPM+ Surprise- LLActRep- BwNot- ASPMOptComp+ > LnkCtl: ASPM L1 Enabled; RCB 64 bytes, LnkDisable- CommClk+ > ExtSynch- ClockPM+ AutWidDis- BWInt- AutBWInt- > LnkSta: Speed 16GT/s, Width x1 > TrErr- Train- SlotClk+ DLActive- BWMgmt- ABWMgmt- > DevCap2: Completion Timeout: Not Supported, TimeoutDis+ NROPrPrP- LTR+ > 10BitTagComp+ 10BitTagReq- OBFF Not Supported, ExtFmt- EETLPPrefix- > EmergencyPowerReduction Not Supported, EmergencyPowerReductionInit- > FRS- TPHComp- ExtTPHComp- > AtomicOpsCap: 32bit- 64bit- 128bitCAS- > DevCtl2: Completion Timeout: 50us to 50ms, TimeoutDis+ > AtomicOpsCtl: ReqEn- > IDOReq- IDOCompl- LTR+ EmergencyPowerReductionReq- > 10BitTagReq- OBFF Disabled, EETLPPrefixBlk- > LnkSta2: Current De-emphasis Level: -6dB, EqualizationComplete+ EqualizationPhase1+ > EqualizationPhase2+ EqualizationPhase3+ LinkEqualizationRequest- > Retimer- 2Retimers- CrosslinkRes: Upstream Port > Capabilities: [b0] MSI-X: Enable- Count=32 Masked- > Vector table: BAR=0 offset=00002000 > PBA: BAR=0 offset=00003000 > Kernel modules: iwlwifi ``` </details> **dom0# lspci -vvv 0s 2f:00.0** <details> ``` > 2f:00.0 Network controller: Intel Corporation Device 272b (rev 1a) > Subsystem: Intel Corporation Device 00f4 > Control: I/O- Mem+ BusMaster- SpecCycle- MemWINV- VGASnoop- ParErr- Stepping- SERR- FastB2B- DisINTx- > Status: Cap+ 66MHz- UDF- FastB2B- ParErr- DEVSEL=fast >TAbort- <TAbort- <MAbort- >SERR- <PERR- INTx- > Interrupt: pin A routed to IRQ 19 > Region 0: Memory at b5500000 (64-bit, non-prefetchable) [size=16K] > Capabilities: [40] Power Management version 3 > Flags: PMEClk- DSI- D1- D2- AuxCurrent=375mA PME(D0+,D1-,D2-,D3hot+,D3cold+) > Status: D0 NoSoftRst+ PME-Enable- DSel=0 DScale=0 PME- > Capabilities: [50] MSI: Enable- Count=1/1 Maskable- 64bit+ > Address: 0000000000000000 Data: 0000 > Capabilities: [70] Express (v2) Endpoint, MSI 00 > DevCap: MaxPayload 128 bytes, PhantFunc 0, Latency L0s unlimited, L1 unlimited > ExtTag- AttnBtn- AttnInd- PwrInd- RBE+ FLReset+ SlotPowerLimit 10W > DevCtl: CorrErr+ NonFatalErr+ FatalErr+ UnsupReq+ > RlxdOrd+ ExtTag- PhantFunc- AuxPwr- NoSnoop+ FLReset- > MaxPayload 128 bytes, MaxReadReq 512 bytes > DevSta: CorrErr+ NonFatalErr- FatalErr- UnsupReq+ AuxPwr+ TransPend- > LnkCap: Port #0, Speed 16GT/s, Width x1, ASPM L1, Exit Latency L1 <64us > ClockPM+ Surprise- LLActRep- BwNot- ASPMOptComp+ > LnkCtl: ASPM L1 Enabled; RCB 64 bytes, Disabled- CommClk+ > ExtSynch- ClockPM+ AutWidDis- BWInt- AutBWInt- > LnkSta: Speed 16GT/s, Width x1 > TrErr- Train- SlotClk+ DLActive- BWMgmt- ABWMgmt- > DevCap2: Completion Timeout: Not Supported, TimeoutDis+ NROPrPrP- LTR+ > 10BitTagComp+ 10BitTagReq- OBFF Not Supported, ExtFmt- EETLPPrefix- > EmergencyPowerReduction Not Supported, EmergencyPowerReductionInit- > FRS- TPHComp- ExtTPHComp- > AtomicOpsCap: 32bit- 64bit- 128bitCAS- > DevCtl2: Completion Timeout: 50us to 50ms, TimeoutDis+ LTR+ 10BitTagReq- OBFF Disabled, > AtomicOpsCtl: ReqEn- > LnkCap2: Supported Link Speeds: 2.5-16GT/s, Crosslink- Retimer+ 2Retimers+ DRS- > LnkCtl2: Target Link Speed: 16GT/s, EnterCompliance- SpeedDis- > Transmit Margin: Normal Operating Range, EnterModifiedCompliance- ComplianceSOS- > Compliance Preset/De-emphasis: -6dB de-emphasis, 0dB preshoot > LnkSta2: Current De-emphasis Level: -6dB, EqualizationComplete+ EqualizationPhase1+ > EqualizationPhase2+ EqualizationPhase3+ LinkEqualizationRequest- > Retimer- 2Retimers- CrosslinkRes: Upstream Port > Capabilities: [b0] MSI-X: Enable- Count=32 Masked- > Vector table: BAR=0 offset=00002000 > PBA: BAR=0 offset=00003000 > Capabilities: [100 v2] Advanced Error Reporting > UESta: DLP- SDES- TLP- FCP- CmpltTO- CmpltAbrt- UnxCmplt- RxOF- MalfTLP- ECRC- UnsupReq- ACSViol- > UEMsk: DLP- SDES- TLP- FCP- CmpltTO- CmpltAbrt- UnxCmplt- RxOF- MalfTLP- ECRC- UnsupReq- ACSViol- > UESvrt: DLP+ SDES+ TLP- FCP+ CmpltTO- CmpltAbrt- UnxCmplt- RxOF+ MalfTLP+ ECRC- UnsupReq- ACSViol- > CESta: RxErr- BadTLP- BadDLLP- Rollover- Timeout- AdvNonFatalErr- > CEMsk: RxErr- BadTLP- BadDLLP- Rollover- Timeout- AdvNonFatalErr+ > AERCap: First Error Pointer: 00, ECRCGenCap+ ECRCGenEn- ECRCChkCap+ ECRCChkEn- > MultHdrRecCap+ MultHdrRecEn- TLPPfxPres- HdrLogCap- > HeaderLog: 00000000 00000000 00000000 00000000 > Capabilities: [148 v1] Secondary PCI Express > LnkCtl3: LnkEquIntrruptEn- PerformEqu- > LaneErrStat: 0 > Capabilities: [158 v1] Physical Layer 16.0 GT/s <?> > Capabilities: [17c v1] Lane Margining at the Receiver <?> > Capabilities: [188 v1] Latency Tolerance Reporting > Max snoop latency: 15728640ns > Max no snoop latency: 15728640ns > Capabilities: [190 v1] L1 PM Substates > L1SubCap: PCI-PM_L1.2+ PCI-PM_L1.1+ ASPM_L1.2+ ASPM_L1.1+ L1_PM_Substates+ > PortCommonModeRestoreTime=10us PortTPowerOnTime=14us > L1SubCtl1: PCI-PM_L1.2+ PCI-PM_L1.1+ ASPM_L1.2+ ASPM_L1.1+ > T_CommonMode=0us LTR1.2_Threshold=116736ns > L1SubCtl2: T_PwrOn=50us > Capabilities: [1a0 v1] Vendor Specific Information: ID=0002 Rev=4 Len=100 <?> > Capabilities: [2a0 v1] Data Link Feature <?> > Capabilities: [2ac v1] Precision Time Measurement > PTMCap: Requester:+ Responder:- Root:- > PTMClockGranularity: Unimplemented > PTMControl: Enabled:+ RootSelected:- > PTMEffectiveGranularity: 4ns > Capabilities: [2b8 v1] Vendor Specific Information: ID=0003 Rev=1 Len=054 <?> > Capabilities: [500 v1] Vendor Specific Information: ID=0023 Rev=1 Len=010 <?> > Kernel driver in use: pciback > Kernel modules: iwlwifi ``` </details>

suffice to say increasing the ram of sys-net to 1gb worked for me. i probably could have let it at around 512-600 but not the 300 default disposable value.

i also had to remove all the other modules besides iwlwifi and iwlmld in my module blacklist file
