How to recreate a Veracrypt-esque hidden partition with LUKS detached header?

User Support General
1

I don’t think I follow a lot of what people are saying on installing LUKS with a detached header. Yes, if my header lives on a USB there’s effectively no way to figure out much about the partition (I believe dmcrypt has some metadata leakage but that can be dealt with).

What I want is a Veracrypt-esque FDE setup: a LUKS encrypted disk with the header file on disk (which doesn’t look very suspicious), and then a hidden partition/container (in which I either run an entirely different OS or just keep to run disp VMs on), with the header for the second partition/container on a USB which I won’t carry with me when crossing borders.

Obviously, this means that the hidden partition must not be visible with forensic tools. I do not think that the guides talking about LUKS encrypted headers on a different drive take this into account. Unfortunately I’m too much of a Linux noob to do this myself so I’m asking the community for help. How do I keep a hidden partition on a LUKS encrypted drive?

I thought it could be done with LVM, i.e. a hidden volume using LVM on top of LUKS (so when someone takes an image of the drive, all they see is gibberish without the password), and when looking inside they cannot see any trace of the “hidden LVM”,

My threat model doesn’t include preserving the material in that hidden partition against duress - if they want to wipe my drive they can feel free to do so.

What do you think I should do?

I might have to go through a situation similar to what I describe here at some point.

2

You can use offset LUKS option for this.
Install the “dummy” OS using the first N GB of the disk without detached header.
Then install the “hidden” OS using the remaining space after N GB with a detached header and boot partitions on a USB.
So when you boot without USB connected you’ll boot into the “dummy” OS and when you connect USB and boot from it you’ll boot from the “hidden” OS.

   --offset, -o <number of 512 byte sectors>
       Start offset in the backend device in 512-byte sectors.

       The --offset option sets the data offset (payload) of data
       device and must be aligned to 4096-byte sectors (must be
       multiple of 8). This option cannot be combined with
       --align-payload option.

cryptsetup-luksFormat(8) - Linux manual page

1 Like
3

Booting into the dummy OS will show that it uses only “N GB” not the full size of the disk. :thinking:

4

It’s the same for VeraCrypt.
You can also create the outer volume like in VeraCrypt e.g.:
partition 1 - 64 GB - decoy OS
partition 2 - the rest of the free space - unencrypted FAT32 volume with up to 10 GB of some non-sensitive files. Don’t write more than 10 GB of data on it.
Create the LUKS partition with 74 GB offset on the disk.
Maybe you can find a better way to create an outer volume if you search for it.
