HCL - MSI GF65 Thin 9SE

User Support HCL Reports
,
1
---
layout:
  'hcl'
type:
  'Notebook'
hvm:
  'yes'
iommu:
  'yes'
slat:
  'yes'
tpm:
  'unknown'
remap:
  'yes'
brand: |
  Micro-Star International Co., Ltd.
model: |
  GF65 Thin 9SE
bios: |
  E16W1IMS.10B
cpu: |
  Intel(R) Core(TM) i7-9750H CPU @ 2.60GHz
cpu-short: |
  i7-9750H
chipset: |
  Intel Corporation 8th/9th Gen Core Processor Host Bridge / DRAM Registers
chipset-short: |
  FIXME
gpu: |
  Intel Corporation CoffeeLake-H GT2 [UHD Graphics 630]
  NVIDIA Corporation TU106M [GeForce RTX 2060 Mobile]
gpu-short: |
  FIXME
network: |
  Intel Corporation Cannon Lake PCH CNVi WiFi
  Realtek Semiconductor Co., Ltd. RTL8111/8168/8211/8411 PCI Express Gigabit Ethernet Controller
memory: |
  65373
nvme: |
  Samsung SSD 970 EVO Plus 2TB
usb: |
  3
certified:
  'no'
versions:
  - works:
      'yes'
    qubes: |
      R4.3.1
    xen: |
      4.19.4
    kernel: |
      7.0.6-1
    remark: |
      Include "set nouveau.modset=0" in GRUB setup
    credit: |
      FIXAUTHOR
    link: |
      FIXLINK

Remarks

Installation Remarks

  • Enable Legacy Mode in BIOS.
  • Disable Secure Boot.
  • Add set nouveau.modset=0 in the installation command list.

Firmware Compatibility

To gain basic control over the camera toggle, fan modes, shift modes, and temperature monitors, the following library must be installed in dom0:

To unlock the computer’s fan curve and to provide an interface for managing the features listed above the following must also be installed:

HDMI Port and GPU Remarks

The HDMI port interfaces solely with the dGPU. To use a secondary monitor one may simply allow it to run from the HDMI port which works out of the box. However, if you are hiding the dGPU for GPU passthrough this leaves the monitor inaccessible to anything except the Qube where the GPU has been attached to.

Undervolting

I was unable to configure undervolting within Qubes, but rather managed to do so through the device’s advanced BIOS settings which may be accessed by entering the BIOS with the Delete key and then pressing: Left Alt + F2 + Right Control + Right Shift. Undervolting through the BIOS is more secure than through the OS anyways to my understanding, but sharing so that people might learn how to accomplish it with similar devices.

Attachments

Qubes-HCL-Micro_Star_International_Co___Ltd_-GF65_Thin_9SE-20260627-163055.yml (1003 Bytes)
