Qube Manager redesign (visual connections between qubes, drag & drop, zooming) (status: mockup)

Zrubi · June 3, 2025, 7:12am

What do you people think? Feedback is highly appreciated.

Use the search before you re invent the wheel

No offfense, but your ‘legal notice’ triggered mee a little do that search for you:
https://groups.google.com/g/qubes-devel/c/64-WJIMY18A/m/-nwwAmhlBAAJ

github.com/QubesOS/qubes-issues

Qubes VM network overview

opened 05:00PM - 10 Dec 20 UTC

closed 03:04AM - 11 Dec 20 UTC

3hhh

C: manager/widget ux P: default

**The problem you're addressing (if any)** It would be nice to be able to o…btain a graphical overview of my Qubes OS machine. **Describe the solution you'd like** Some sort of interactive GUI providing the following features: - each VM displayed as some rectangle with its name inside, colored in the respective VM color - Lines between VMs according to their network connections (VM A has netvm B: `A -- B`) - ideally not overlapping too much - grouping by VM colors supported - filtering or removing certain VMs from the picture is possible - ideally template VMs are displayed hidden behind their instances with only their name visible at the top - temporary renaming of certain VMs just for the picture (for sharing) - adding Notes to VMs is possible - saving and loading (svg format or so?) **Where is the value to a user, and who might that user be?** - easy sharing of one's setup or potential setups - doc - quick identification of erroneous network setups **Describe alternatives you've considered** I currently do it myself with inkscape. **Additional context** Actually something like the pictures of [Joanna's post](https://theinvisiblethings.blogspot.com/2011/03/partitioning-my-digital-life-into.html), just automatically generated from an existing Qubes OS instance. **Relevant [documentation](https://www.qubes-os.org/doc/) you've consulted** . **Related, [non-duplicate](https://www.qubes-os.org/doc/reporting-bugs/#new-issues-should-not-be-duplicates-of-existing-issues) issues** None?

github.com/QubesOS/qubes-issues

[Contribution] qubes-network-topology

opened 08:51AM - 13 Jan 17 UTC

andrewdavidwong

ux P: default community dev S: needs review C: contrib package C: networking

**Community Dev:** @Zrubi **PoC:** https://gist.github.com/Zrubi/6229d5400bde98…7b1aa8da516553b909 ----- Several users over the years have requested a feature that allows them to visualize the topography of their VMs in the form of a graph, and some of our users have even developed tools that accomplish these. We should consider selecting and integrating one of these tools into Qubes. Discussion threads: * https://groups.google.com/d/topic/qubes-users/EPuXNkSFxdE/discussion * https://groups.google.com/d/topic/qubes-devel/64-WJIMY18A/discussion

gist.github.com

https://gist.github.com/Zrubi/6229d5400bde987b1aa8da516553b909

qubes-network-topology

#!/usr/bin/python2
# -*- encoding: utf8 -*-
#
# The Qubes OS Project, http://www.qubes-os.org
#
# Copyright (C) 2016  Laszlo Zrubecz <mail@zrubi.hu>
#
# This program is free software; you can redistribute it and/or
# modify it under the terms of the GNU General Public License
# as published by the Free Software Foundation; either version 2

This file has been truncated. show original
